JBL 1500 - Page 16

Part numbe
r
Qt
y
Description Reference Designato
r
Mechanical Parts
073-111004-000ZR 1 GR shorting strap 29.5x12.4x0.8m/m J9
074-300018-000ZR 1 GR RELAY PN:943-1C-48D K1
008-061215-000ZR 1 GR GASKET C4305 12x15 t=5mm CR spa thermistor
008-061602-022ZR 2
GR GASKET CR4305 spa 155.8x16.8 t=1.5mm (UL94-HF1) plate x2
008-063702-002ZR 2
GR GASKET CR4305 spa 372.3x16.1 t=1.5mm (UL94-HF1) Plate x2
008-065757-002ZR 1 GR GASKET CR4305 spa 56.9x57.2 t=1.0mm (UL94-HF1) X'FORMERPLATE
061-001052-000ZS 2 GS Knob w/white indicator 49001-W (18 t)D=15.1 H=14.5 GAIN, CROSSOVER KNOBS
061-100016-000ZR 7 GR post PN:BCMS-8 L=8mm NYLON 66(UL) POWER PCBx4,FUSE PCBx3
061-700044-000ZR 2 GR mica 13x18mm TO-220 holeless for Q13,17
061-700090-900ZR 2 GR ceramic washer 16x21mm t=2mm white for Q11,15
061-700119-000ZR 1 GR insulator 114.3x84mm t=0.254mm FR700 POWER PCB
061-701003-000ZR 1 GR insulator w/adhesive M 467 170x85mm t=0.432mm bracket+plate
063-010010-000ZR 5 GR Transistor Bracket P/N:TRK-2 for Q11,13,15,17,TH1
063-060606-000ZR 1 GR X'FORMER PLATE SPCC 56.9x57.2 t=2.0mm
063-401602-000ZR 1 GR Plate SPCC (1500 Array) 402x156.8 t=2.3mm
073-014103-500ZR 1 GR Bracket (HB5000) 6.64"x3.5"x3.2" SPCC platex1
073-032141-600ZR 1 GR Heatsink (HB5000) 82.8x120.7x19.1mm black anodiz bracketx1
074-020005-000ZR 1 GR 2-pin AC socket P/N 3516-T3C02 AC POWER Receptacle
074-020018-000ZR 1 GR ROCKER SW (AC POWER) PN:RF1003-BB4-0 SW4
086-021836-004ZR/120V
1
GR Power cord SJT 16AWGx2C L=3660mm WS004+WS002E
AC POWER Cord
FOR MAIN POWER TRANSFORMER SEE EXPLODED VIEW
15
1500 Array Subwoofer
