SERVICE BULLETIN JBL2000-01 - JANUARY 2000
To all JBL Service Centers Warranty labor rate: MINOR repair
Model: ARC SUB10 / DS-10
Subject: Failure of C6
In the event you receive a JBL subwoofer corresponding to one of the above models with the complaint “no output” and
capacitor C6 (10uf 50v NPE) is damaged in the amplifier, replace with the following part: JBL part# 30712 (10uf 100v NPE)
General reference for location only; not all parts or designators may conform to these drawings
It is also recommended following the repair that the instructions included in bulletin #JBL9903 are followed.
Models Serial number 120/230V Status Action
ARC SUB10 / DS-10 All serial numbers affected
Replace if damaged Replace C6 with JBL part# 30712
15
Amplifier/Subwoofer ARC SUB10/DS-10
