ARC SUB10/DS-10 ELECTRICAL PARTS LIST
Product Safety Notice: Components identified by the IEC symbol in the part list
and on the schematic designate safety components in which safety can be of
special significance. When replacing a Active component with the symbol . Use
only replacement parts with the same rating hardware designated in the parts list.
Capacitors
C1, C2 30701 3300uF 50V ±20% Elect. Radial Safety Part 2
C3, 4, 5, 8, 9, 30502 100nF 50V ±10% Mono-ceramic axial 12
10, 14, 17, 18,
19, 20, 24
C6 30705 10uF 100V ±20% Elect. Radial NP Safety Part1
See Page 15 Service Bulletin
C7A, B 30505 100nF 100V ±20% Metal Polyester Rad 2
C7 30509 2.7nF 50V ±10% Mono-ceramic axial 1
C10 30504 100nF 50V ±10% Mono-ceramic axial 1
C11 30702 100uF 35V ±20% Electrolytic Radial 1
C12 30714 10uF 35V ±20% Electrolytic Radial 1
C13 30506 1nF 50V ±10% Mono-ceramic axial 1
C15, 16 30704 or 30707 220uF 50V ±20% Electrolytic Radial Bipolar 2
C21, 28 30507 10nF 50V ±20% Mono-ceramic axial 2
C25 30503 2.2nf 50V ±10% Mono-ceramic axial 1
Diodes
DBR 50100 Bridge Rect 200V 4A Safety Part 1
D1 50101 1N5256B 30V ±5% 0.5W Zener 1
D3 50102 1N4749A 24V ±5% 1W Zener 1
D6 50103 1N5234B 6.2V ±5% 0.5W Zener 1
D7, 8 50104 1N4148 100V ±5% 0.1A 2
D9,10 50105 1N4744A 15V ±5% 1W Zener 2
LED 1 or 2 50106 Dual Cir LED (2 legged)
Integrated Circuit
U1 60100 LM324 Quad OpAmp +/-15 1
Resistors
FRQ pot 40401 100kW 0.25W ±10% Single Log Pot 1
VOL Level pot 40402 5kW 0.25W ±10% Single Linear Pot 1
R1 40403 2.2MW 0.25W ±5% carbon film 1
R2 40408 8.45kW 0.25W ±1% metal film 1
R3 40412 33.2kW 0.25W ±1% metal film 1
R4A, B 40105 0.1W 0.5W ±5% 2pcs. 2
R5, 6 40420 1kW 0.25W ±5% carbon film 2
R7 40718 3.3kW 0.25W ±5% carbon film 1
R8 40417 47kW 0.25W ±5% carbon film 1
R9 40421 3.9kW 5W ±5% 3W can be used 1
R10, 13 40748 2kW 2W ±5% carbon film 2
R11, 12 40112 665W 0.5W ±5% carbon film 2
R14, 20 40405 4.7kW 0.25W ±5% carbon film 2
R15, 42, 43, 57 40406 100kW 0.25W ±5% carbon film 4
R16 40101 820W 2W ±5% carbon film 2
R17 40407 330kW 0.25W ±5% carbon film 1
R18 40423 270kW 0.25W ±5% carbon film 1
R19 40422 1kW 0.5W ±5% carbon film 1
R22 40410 2.2kW 0.5W ±5% carbon film 1
R26 40701 1.0MW 0.25W ±5% carbon film 1
R27 40411 24.9kW 0.25W ±1% metal film 1
R29 40103 470W 0.25W ±5% METAL OXIDE Safety Part 1
R30 40413 274kW 0.25W ±1% metal film 1
R31 40414 49.9kW 0.25W ±1% metal film 1
R32 40415 470kW 0.25W ±5% carbon film 1
R35 40424 332kW 0.25W ±1% metal film 1
R36, 38, 40 40417 47kW 0.25W ±5% carbon film 3
R37 40418 22kW 0.25W ±5% carbon film 1
R39, 48 40419 6.04kW 0.25W ±1% metal film 2
R46 40111 4.7W 0.25W ±5% carbon film 1
R49 40431 68kW 0.25W ±5% carbon film 1
R53, 54, 55, 56 40106 100W 2W ±5% carbon film 4
Transistors
Q1 60151 MPS A13 30V NPN(Darl) Transistor 1
Q2 60152 2N3906 40V PNP Transistor 1
Q3 60156 2N4401 40V NPN Transistor 1
Q4, 5 60154 MPS A56 80V PNP Transistor 2
Miscellaneous
S53AMI 60301 Power Amp module Safety Part 1
CMC1 80100 2.2mH Choke Safety Part 1
L1 80101 110uH Choke Safety Part 1
L2 80102 2.2uH Ferrite Bead 1
TRX 80108 TRANSFORMER #4338 Safety Part 1
F1 80109 FUSE 250V, 0.63A, T type Slo-Blo Safety Part 1
