JBL ARC SUB10 User Manual

ARC SUB10/DS-10 BLOCK DIAGRAM
9
Amplifier/Subwoofer ARC SUB10/DS-10
Summing
Circuit
Volume
Control
Equalization
Waveform
Recovery and
Fixed Low Pass
Crossover
Control
Power
Amplifier
Short Circuit
Protection
Woofer
LR
SPKR
In
SPKR
Out
High Level
Input
Low Level In
R
L
Low Level
Input
E
E
D
D
C
C
B
B
A
A
7
7
6
6
5
5
4
4
3
3
2
2
1
1

JBL ARC SUB10 Specifications

Power

amplifier power	100 watts

Driver

driver size	10 inches

Inputs and Outputs

inputs	Line- and high-level
outputs	High-level with high-pass filter at 180Hz

Frequency

crossover frequency	50Hz – 150Hz
frequency response	35Hz – 150Hz

Weight and Dimensions

dimensions	11-1/2 x 17-1/8 x 16-1/2 inches
dimensions metric	292 x 435 x 419mm
weight	27 lbs/12.3 kg
