JBL BAR 5.0 MULTIBEAM User Manual

www.jbl.com
English
33
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 2
1. INTRODUCTION 4
2. WHAT’S IN THE BOX 5
3. PRODUCT OVERVIEW 6
3.1 SOUNDBAR 6
3.2 REMOTE CONTROL 7
4. PLACE 7
4.1 DESKTOP PLACEMENT 7
4.2 WALL-MOUNTING 8
5. CONNECT 8
5.1 CONNECTION WITH YOUR TV AND DIGITAL DEVICES 8
5.2 BLUETOOTH CONNECTION 10
5.3 CONNECTION WITH YOUR HOME NETWORK 11
6. SETUP 14
6.1 POWER-ON/AUTO STANDBY/AUTO WAKEUP 14
6.2 SOUND CALIBRATION 14
7. PLAY 16
7.1 PLAY FROM THE TV SOURCE 16
7.2 PLAY FROM THE HDMI IN SOURCE 16
7.3 PLAY FROM THE BLUETOOTH SOURCE 17
7.4 PLAY THROUGH CHROMECAST BUILT-IN 17
7.5 PLAY THROUGH AIRPLAY 17
7.6 PLAY THROUGH AMAZON MUSIC 17
7.7 MULTI-ROOM PLAYBACK 18
8. SOUND SETTINGS 19
9. RESTORE FACTORY SETTINGS 19
10. SOFTWARE UPDATE 20
11. PRODUCT SPECIFICATIONS 21
12. TROUBLESHOOTING 22
13. TRADEMARKS 23
14. OPEN SOURCE LICENSE NOTICE 24

JBL BAR 5.0 MULTIBEAM Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 / 60 Hz
Package type	Box
Package depth	966 mm
Package width	161 mm
Package height	129 mm
Package weight	4530 g
Audio decoders	Dolby Atmos
RMS rated power	- W
Audio output channels	5.0 channels
Audio Return Channel (ARC)	Yes
Cables included	HDMI
HDMI in	1
HDCP version	2.3
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Soundbar speaker RMS power	250 W
Subwoofer type	Active subwoofer
Subwoofer sensitivity	92 dB
Subwoofer frequency range	50 - 20000 Hz
Product color	Black
TV stand usage	-
Audio formats supported	MP3
Network streaming services supported	Chromecast

Weight and Dimensions

Depth	100.5 mm
Width	709 mm
Height	60.5 mm
Soundbar weight	2800 g
