Part Number Description Qty Reference Designators
PREAMP PCB
174-0rcb202vag RCA JACK RCA-209 GOLDEN LINE IN DUAL 1 JK202
175-1c07v01 WIRE CONNECTOR&BASE 7PIN PITCH=2.5mm 1 M201
180-tms7210v SWITCH SLIDE 6PIN MS7210V AUTO ON 1 SW201
180-sms50126 SWITCH SLIDE SW MS50126 PHASE 1
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 012-7500-00022)
Resistors
118-12061001j SMD RESISTOR 1.00K 1206 5% 4 R2,R11,R29,R30
118-12061002j SMD RESISTOR 10.0K 1206 5% 3 R7,R9,R25
118-120610r0j SMD RESISTOR 10.0Ω 1206 5% 2 R22,R23
118-12061201j SMD RESISTOR 1.20K 1206 5% 16
R31,R32,R33,R34,R35,R36,R37,R38,R39,R40,
R41,R42,R43,R44,R45,R46
118-12062002j SMD RESISTOR 20.0K 1206 5% 1 R26
118-12062201j SMD RESISTOR 2.20K 1206 5% 3 R6,R13,R16
118-12062701j SMD RESISTOR 2.70K 1206 5% 1 R10
118-12063000j SMD RESISTOR 300.0Ω 1206 5% 1 R24
118-12063301j SMD RESISTOR 3.30K 1206 5% 4 R14,R15,R27,R28
118-12063902j SMD RESISTOR 39.0K 1206 5% 1 R3
118-12064700j SMD RESISTOR 470Ω 1206 5% 1 R8
118-12064701j SMD RESISTOR 4.70K 1206 5% 3 R1,R5,R12
118-12064702j SMD RESISTOR 47.0K 1206 5% 1 R17
118-12064704j SMD RESISTOR 4.70M 1206 5% 1 R4
118-120647r0j SMD RESISTOR 47.0Ω 1206 5% 2 R20,R21
Capacitors
141-c0101k50 SMD CAPACITOR 100pF 50V 10% 1206 NP0 1 C4
141-c0220k50 SMD CAPACITOR 22pF 50V 10% 1206 NPO 1 C5
141-c0561k50 SMD CAPACITOR 560pF 50V 10% 1206 NPO 1 C6
141-c5104m50 SMD CAPACITOR 1206 Y5V 0.1uF 50V ±20% 8 C2,C3,C7,C8,C9,C10,C11,C15
141-c7223k50 SMD CAPACITOR 0.022uF 50V 10% 1206 X7R 1 C13
141-d7104ka0 SMD CAPACITOR 0.1uF 100V 10% 1210 X7R 2 C12,C14
141-d7104kb5 SMD CAPACITOR 0.1uF 250V 10% 1210 X7R 4 C1,C18,C19,C20
128-e106ma01 CROSSVER CAP 10uF 100V 20% 2 C16,C17
Semiconductors
190-16tl072dts SMD I.C. TL072CDT DUAL OP-AMP SGS THOMSON 1 IC1
192-09124126qs SMD TRANSISTOR 2SC2412K-T146Q/R ROHM 3 Q1,Q4,Q5
192-09139066rs SMD TRANSISTOR 2SC3906K-T146R ROHM 2 Q2,Q8
192-09210376qs SMD TRANSISTOR 2SA1037K-T146Q/R ROHM 2 Q7,Q9
192-09215146rs SMD TRANSISTOR 2SA1514K-T146R ROHM 2 Q3,Q6
197-03rls4148s SMD DIODE RLS4148-TE11 ROHM 6 D1,D2,D3,D4,D5,D6
199-15000563s SMD ZENER 5.6V 5% PHILIPS BZX84-C5V6 2 Z1,Z2
199-1500120s-e SMD ZENER 12V 5% PHILIPS BZX84-C12 (RoHS) 2 Z5,Z6
199-15001503s SMD ZENER 15V 5% PHILIPS BZX84-C15 2 Z3,Z4
192-232irf9640 FET IRF9640 IR P-CH TO220 1 Q10
192-233f640n TRANSISTOR IRF640N INTERNATIONAL 1 Q11
Miscellaneous
122-14121m4191 Ferrite core LS-A6206-ST EFD-30 1 L1
122-14350j4180 CHOKE COIL 35uH Ferrite Core 25 Milliohm 1 L2
123-11rc6*30wd BOBBIN(NI-ZN)RC6*30 1
175-9f40hr2 WIRE CNCT+B220R&BASE 40PIN PIT=2.54mm HR2*40
