Part Number Description Qty Reference Designators
MAIN PCB
Resistors
110-14103j26 Resistor 10K 1/4W ±5% 26mm 3 R503,504,510
110-14222j26 Resistor 2.2K 1/4W ±5% 26mm 1 R511
110-14432j26 Resistor4.3K 1/4W ±5%CF 26mm 1 R506
110-14472j26 Resistor 4.7K 1/4W ±5% CF 26mm 1 R505
110-16102j26 Resistor 1K 1/6W ±5% CF 26mm 1 R153
110-16103j26 Resistor 10K 1/6W ±5% CF 26mm 10 R128,130,149,150,305,306,308,311,314,319
110-16104j26 Resistor 100K 1/6W ±5% CF 26mm 3 R122,126,307
110-16153j26
Resistor 15K 1/6W ±5% CF 26mm
1 R107
110-16182j26
Resistor 1.8K 1/6W ±5% CF 26mm CF
1 R145
110-16203j26
Resistor20K 1/6W ±5% CF 26mm
1 R390
110-16221j26
Resistor 220Ω 1/6W ±5% CF 26mm
1 R144
110-16222j26
Resistor2.2K 1/6W ±5% CF 26mm
1 R102
110-16223j26
Resistor 22K 1/6W ±5% CF 26mm
1 R316
110-16333j26
Resistor 33K 1/6W ±5% CF 26mm
1 R310
110-16393j26
Resistor 39K 1/6W ±5% CF 26mm
1 R515
110-16473j26
Resistor 47K 1/6W ±5% CF 26mm
2 R106,129
110-16474j26 Resistor 470K 1/6W ±5%CF 26mm 1 R127
110-16434j26 Resistor 430K 1/6W ±5% CF 26mm 1 R312
110-16562j26 Resistor 5.6K 1/6W ±5% CF 26mm 1 R152
110-16621j26 Resistor620Ω 1/6W ±5% CF 26mm 1 R160
110-16751j26 Resistor 750Ω 1/6W ±5% CF 26mm 1 R315
110-16755j26 Resistor 7.5M 1/6W ±5% CF 26mm 1 R313
116-161002f26 Resistor10K 1/6W ±1% MF 26mm 2 R301,303
116-161202f26 Resistor12.00K 1/6W ±1% MF 26mm 1 R302
110-20332jk3 Resistor 3.3K 2W ±5% CF7.5m 1 R134
113-50s68j00 cement Resistor 0.068Ω 5W ±5% 1 R147
116-201001jk3x metal film Resistor 1.00K 2W ±5% 7.5mm 1 R148
116-304700jk2x metal film Resistor 470Ω 3W ±5% 10mm 2 R501,502
Capacitors
116-162200f26
disc capacitor220Ω 1/6W ±1% MF 26mm
1 R317
116-162202f26
disc capacitor22.0Ω 1/6W ±1% MF 26mm
1 C318
130-3f104z503
disc capacitor0.1U 50V+80/-20%
6 C107,117,122,144,320,322
130-s1101k503 mylar capacitor 100P 50V SL ±10% 3 C302,,303,306
132-103j503 mylar capacitor 0.01uF 50V ±5% 2 C305,317
132-103j504 mylar capacitor 0.01uF100V ±5% 2 C103,104
132-104ja03 mylar capacitor 0.01uF100V ±5% 3 C123,503,504
132-273ja03 mylar capacitor 0.027uF100V ±5% 1 C143
135-3106m10 Electrolytic capacitor10U50V ±20% 2 C319,321
135-3107m10 Electrolytic capacitor100U 10V ±20% 2 C114,115
135-3107m35 Electrolytic capacitor100U 35V ±20% 2 C507,508
135-3225m50 Electrolytic capacitor2.2U 50V ±20% 1 C509
135-3226m16 Electrolytic capacitor22U 16V ±20% 1 C304
135-3226m50 Electrolytic capacitor22U 16V ±20% 2 C505,506
135-3227m16 Electrolytic capacitor220U 16V ±20% 1 Q118
135-3476m16 Electrolytic capacitor47U 16V ±20% 1 C318
132-103kd00 mylar capacitor 0.01uF 400V ± 10% 1 C500
138-5478m80 Electrolytic Cap 4700uf 80V 20% 2 C501,502
Semiconductors
192-027c1815gr
TRANSISTOR 2SC1815GR NPN
5 Q108,109,113,301,302
192-207c2235y Transistor 2SC2235Y NPN 1 Q111
192-028a1015gr Transistor 2SA1015GR PNP
3 Q101,107,112
192-1572n5551 Transistor 2N5551 NPN 2 Q114,115
192-1582n5401
transistor FSC 2N5401 AI-PNP 350V500mA TO-92
1 Q503
197-031n4148 diode 100mA 75V SIGNAL IN4148 ROHM 7 D102,103,104,105,143,301,302
