Part Number Description Qty Reference Designators
MAIN PCB
199-15000625 zener diode 6.2V 1/2W52mm 1 D101
199-15000605 zener diode 16V 1/2W52mm 1 D502
190-16t1074cn IC TL074CN ST DUAL OP-AMP 1 U301
192-161tip31c Transistor TIP31C SGS NPN 1 Q501
192-162tip32c Transistor TIP32C SGS PNP 1 Q502
197-00kbu606g diode 6A 800V KBU606G BRIDGE 1 D501
197-141n4004 diode 1N4004 2 D110,504
Miscellaneous
109-1ttc802j0 thermister TTC-802(JS) NTC 1 TH1
120-1000003 inductor 10W AI YT-C3104-005 ICRHW 2 FB1,FB2
171-urwh124d relay RWH-SH-124D (1600ohm) 1 RL1
162-50129001 wire cable ass'y 120mm AWG28 WHT 1 W201
175-1d02v01 wire connector 2PIN PITCH=3.96mm 1 M100
175-1d03v01 wire connector 3PIN PITCH=3.97mm 1 M500
MISCELLANEOUS/MECHANICA
L
130-3f104z503 disk cap 0.1U 50V +80/-20% 1 On Power Switch
350-FM04012D106 oval head wood screw with nickel ψ4*12 4
352-AM03010D066 pan head ping P screw with nickel ￠3*10 2
352-AM03008D041 pan head ping B screw with nickel ￠3*8 4
150-r4055900 power transformer I/P:120V/60HzTT0900008720 1 T501
152-U602015 line cord SVT FT-2 6FT 1 Power Cord
154-k31505t0 fuse 3.15A 250V 30mmUL/CSA/PSE 1 F501
155-63032i fuse holder HTB-32I 30mmUL/CSA 1 for F501
180-pbr12c11s power switch PUSH BR12C11S 1 SW501
162-10082007 WIRE RED 18AWG 80mm#1015 1
362-FE-00013 PCB bracket TYPE L t=1.6mm S.P.C.C 89*9*1.6T 2
311-ABS-00028 plastic knob LEVEL 1 for LEVEL control
306-ABS-00004 REAR PLASTIC CABINET 268*213*102 A B S UL 1
335-NYL-00002 strain relief bushing 4K-4 NO-BB 2
176-wjcel lose-end connect CE-1 1
333-EVA-00096 EVA gasket 213*15*2mm 2
333-EVA-00097 EVA gasket 213*15*1mm 2
333-EVA-00132 EVA gasket 238*15*2mm 2
333-EVA-00133 EVA gasket 238*15*1mm 2
333-EVA-00220 EVA gasket 225*15*1mm 1
333-EVA-00188 EVA gasket 170*5*1mm 1
193-201815t2 insulator 2
352-HM03012D086 round washer head ping B screw with black zinc ￠3*1
2
1
317-000-00037 earthing terminal 0.3t 1
323-AL-00056 natured heat sink 83.5*50.5*27.5 1
333-EVA-00219 EVA gasket 150*15*1 1
351-AM03008A078 pan head machine screw with nickel M3*8 7
302-AL-00020-2LA
E
rear pnl css10 silver 270*215*2.5mm (ROHS) 1
351-AM02006A384 pan head machine screw with nickel M2.0*6 2
162-a040d00-e speaker line #1015 400mm(ROHS) 1
CSS10 Cinema Sound
14
