JBL ES250PW - Electrical Parts List; Main;Power Supply PCB Components

ES250PW (120v) Electrical Parts List
Part Number Description Qty Reference Designator
MAIN/POWER SUPPLY PCB
Resistors
109-1TSC103J0-E Resistor TSC05103J 10K +/-5% (RoHS) 1 R237,
110-12621J15-E Resistor 620Ω 1/2W ±5% 15mm(RoHS) 1 R238,
110-20152J20-E Resistor 1.5K 2W ±5% CF 20mm KINK(RoHS) 1 R208,
116-142003F26-E Resistor 200K 1/4W ±1% MF26mm (RoHS) 1 R209,
110-16153J26-E Resistor 15K 1/6W ±5% CF 26mm (RoHS) 2 R247,R249,
110-16182J26-E Resistor 1.8K 1/6W ±5% CF 26mm(RoHS) 1 R248,
110-16274J26-E Resistor 270K 1/6W ±5% CF 26mm(RoHS) 1 R240,
110-16333J26-E Resistor 33K 1/6W ±5% CF 26mm(RoHS) 1 R211,
110-16391J26-E Resistor 390Ω 1/6W CF 26mm (RoHS) 2 R243,R246,
110-16683J26-E Resistor 68K 1/6W ±5% CF 26mm (RoHS) 1 R212,
112-14101J26-E Resistor 1/4W100ohm 5% (RoHS) 2 R241,R244,
116-161002F26-E Resistor 10K 1/6W ±1% MF 26mm (RoHS) 2 R234,R235,
116-161301F26-E Resistor 1.30K 1/6W MF 26mm (RoHS) 3 R226,R228,R236
116-161692F26-E Resistor 16.9K 1/6W MF 26mm (RoHS) 1 R214,
116-162001F26-E Resistor 2.00K 1/6W ±1% MF26mm (RoHS) 1 R215,
116-162492F26-E Resistor 24.9K 1/6W ±1% MF26mm (RoHS) 2 R257,R258,
116-166813F26-E Resistor 681K 1/6W ±1% MF26mm (RoHS) 1 R262,
116-141R00J26X-E Resistor 1.00Ω 1/4W±5% MO 26mm 2 R255,R256,
110-16102J26-E Resistor 1K 1/6W ±5% CF 26mm (RoHS) 3 R210,R239,R264
110-16103J26-E Resistor 10K 1/6W ±5% CF 26mm (RoHS) 9
R216,R227,R229,R230,R231,R232,R233,R260,
R261
110-16222J26-E Resistor 2.2K 1/6W ±5% CF 26mm(RoHS) 2 R242,R245,
110-16223J26-E Resistor 22K 1/6W ±5% CF 26mm (RoHS) 3 R218,R220,R223
110-16472J26-E Resistor 4.7K 1/6W ±5% CF 26mm (RoHS) 4 R213,R217,R219,R222
110-16473J26-E Resistor 47K 1/6W ±5% CF 26mm (RoHS) 1 R221,
113-50R10J10-E Resistor 0.1Ω 5W ±5% 立式(RoHS) 2 R224,R225,
Capacitors
140-RX103KA03-E Capacitor 10nF 100V X7R 10%(RoHS) 1 C174,
135-4228M35-E capacitor 2200uF 35V ±20%(RoHS) 2 C170,C171,
135-4688M80-E Capacitor 6800U 80V ±20%(RoHS) 2 C168,C169,
130-2b102k503-e Capacitor 1000P 50V ±10% (RoHS) 1 C165,
130-3F104Z503-E Capacitor 0.1U 50V +80/-20% (RoHS) 2 C163,C164,
130-CH101J503-E Capacitor 100P 50V ±5% (RoHS) 2 C159,C160,
135-3107M16-E Capacitor 100uF 16V ±20% (RoHS) 2 C166,C167,
135-3226M50-E Capacitor 22U 50V ±20% (RoHS) 2 C161,C162,
135-3227M10-E Capacitor 220U 10V ±20% (RoHS) 2 C156,C157,
139-3227M16-E Capacitor 220uF 16V±20% (RoHS) 1 C155,
140-RX473KB53-E Capacitor 47NF 250V X7R±10% (RoHS) 2 C172,C173,
130-3F104ZA03-E Capacitor 0.1U 100V (RoHS) 2 C168A,C169A
Semiconductors
192-991d669a-e transistor HI-SINCERITY HSD669A (RoHS) NPN 1 Q116,
192-992B649T-E transistor HSB649T (RoHS) PNP 1 Q118,
197-00KBU1003-E Rectifier 10A 200V KBU1003(RoHS) BRIDGE 1 D123,
197-101N4002-E Diode 1N4002TB (RoHS) 1 D114,
190-16LM324N-E I.C. LM324N (RoHS) QUAD OP-AMP 1 U107,
190-16L431CLP1-E
IC TL431CLP (RoHS) PROGRAMMABLE VOLTAGE REFERENCE
1 D115,
192-027C1815GR-E transistor 2SC1815GR TOSHIBA(RoHS) NPN 4 Q110,Q112,Q114,Q117
192-028A1015GR-E transistor 2SA1015GR TOSHIBA(RoHS) PNP 3 Q111,Q113,Q115
192-1572N5551-E transistor FSC 2N5551 (RoHS) NPN 1 Q109,
192-1582N5401-E Transistor FSC 2N5401 AI-PNP 350V500mA TO-92 (RoHS) 1 Q108,
197-00DB103G-E Rectifier 1A 200V DF02MDB103G (RoHS) BRIDGE 1 D124,
199-65000563G-E Diode GDZJ5.6B 500mW 5.6V26mm 2% (RoHS) 1 D116,
199-65001503G-E Diode GDZJ15C500mW 15V 2%ROHM 52mm 1N5245B (Ro 1 D122,
199-65002003G-E Diode GDZJ20D 500mW 20V26mm 2% (RoHS) 1 D129,
24
ES250PW
