JBL ES250PW - Input;Preamp PCB Components; Miscellaneous Components; EQ Daughter Board PCB Components

Part Number Description Qty Reference Designator
MAIN/POWER SUPPLY PCB
197-631N4148-E Diode 500mW 75V 1N4148 Panjit (RoHS) 7 D117,D118,D119,D120,D121,D125,D126
Miscellaneous
175-1C02V01-E Connector 2PIN PITCH=2.5mm (RoHS) 1 P108,
120-1000003-E Inductor 10W AI YT-C3104-0051CRHW354708LTBS LF 2 J161,J165,
175-1c06v01-e Connector 6 PIN PITCH=2.5mm(RoHS) 1 P107,
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 1
171-UDHSS124D-E Relay 5A 24V UDH-SS124D(RoHS) 1 K101,
175-1d02v01-e Connector 2PIN PITCH=3.96mm(RoHS) 1 P112,
175-1d05v01-e Connector 5PIN 3.96mm (RoHS) 1 P113,
INPUT/PREAMP PCB
Resistors
118-08050000J-E SMD Resistor 0805 1/10W 0Ω±5%LF 2 JP1,JP3,
118-08051000F-E SMD Resistor 0805 1/10W 100 ±1% LF 6 R314,R315,R125,R151,R152,R215,
118-08051001J-E SMD Resistor 0805 1/10W 1K ±5% LF 6 R400,R401,R405,R406,R410,R140,
118-08051002F-E SMD Resistor 10.0K 0805 1/10W 1%(RoHS) 17
R330,R331,R111,R117,R118,R122,R124,R133,
R136,R146,R149,R308,R199,R263,R130,R131,
R132,
118-08051002J-E SMD Resistor 0805 1/10W 10KΩ ±5%LF 2 R402,R403,
118-08051004F-E SMD Resistor 0.1W 1M 1% (RoHS) 1 R145,
118-08051053F-E SMD Resistor 0805 105K 1/10W ±1%(RoHS) 1 R135,
118-08051201J-E SMD Resistor 1.2K 0805 1/10W 5%(RoHS) 1 R409,
118-08051500F-E SMD Resistor 0805 150ohm 1% (RoHS) 1 R139,
118-08051504F-E SMD Resistor 0805 1/10W 1.5M ±1%(RoHS) 1 R142,
118-08051542F-E SMD Resistor 0805 1/16W 15K4 ±1%LF RoHS 2 R197,R198,
118-08051802J-E SMD Resistor 18K 0805 1/10W 5%(RoHS) 1 R147,
118-08052001F-E SMD Resistor 0.1W 1% 2K (RoHS) 1 R202,
118-08052002F-E SMD Resistor 0805 20.0K 1% (RoHS) 2 R200,R193,
118-08052200J-E SMD Resistor 0805 1/10W 220Ω 5%(RoHS) 11
R411,R332,R333,R119,R120,R154A,R155A,R15
9A,R160A,R334,R335,
118-08052202F-E SMD Resistor 0805 1/10W 22K±1%(RoHS) 2 R141,R148,
118-08052202J-E SMD Resistor 0805 1/10W 22KΩ ±5%LF 1 R404,
118-08052212F-E SMD Resistor 0805 22.1K 1% (RoHS) 2 R204,R206,
118-08052262F-E SMD Resistor 0805 22.6K 1% (RoHS) 4 R209,R296,R297,R298,
118-08052803F-E SMD Resistor 0805 280K 1/10W ±1%(RoHS) 1 R208,
118-08053011F-E SMD Resistor 0805 3.01K 1% (RoHS) 1 R194,
118-08053301J-E SMD Resistor 0805 1/10W 3.3K ±5%(RoHS) 1 R407,
118-08053401F-E SMD Resistor 3.4K 0805 1/10W 1%(RoHS) 1 R128,
118-08054301F-E SMD Resistor 0.1W 1% 4.3K(RoHS) 1 R254,
118-08054421F-E SMD Resistor 0.1W 1% 4.42K(RoHS) 2 R205,R207,
118-08054701F-E SMD Resistor 4.7K 0805 1% (RoHS) 1 R144,
118-08054702J-E SMD Resistor 47K 0805 1/10W 5%(RoHS) 9
R109,R114,R115,R116,R121,R137,R138,R219,
R412,
118-08054703J-E SMD Resistor 470K 0805 1/10W 5%(RoHS) 1 R143,
118-08054991F-E SMD Resistor 4.99K 0805 1/10W 1%(RoHS) 1 R265,
118-08054R70F-E SMD Resistor 0805 1/10W 4.7 ±1%(RoHS) 1 R153,
118-08055101F-E SMD Resistor 5.1K 0805 1/10W 1%(RoHS) 8 R316,R317,R318,R319,R320,R321,R322,R323,
118-08055363F-E SMD Resistor 0805 536K 1/10W ±1%(RoHS) 1 R195,
118-08056491F-E SMD Resistor 0805 6.49K 1% (RoHS) 1 R134,
118-08056801F-E SMD Resistor 6.8K 0805 1/10W 1%(RoHS) 6 R300,R301,R110,R112,R113,R123,
115-H103A101-E Resistor A10K (RoHS) LEVEL 1 VR1,
115-H503B405-E Resistor B50K (RoHS) CROSSOVER 1 VR2,
Capacitors
141-B0101J50-E CAP CERAMIC/CHIP 100PF 50V CHJNPO 0805 RoHS 5 C318,C319,C331,C332,C110B,
141-B0221J50-E SMD capacitor 220P 50V NPO 0805(RoHS) 3 C304,C305,C212,
141-B0330J50-E SMD capacitor 0805 33pF5% 50V(RoHS) 1 C148,
141-B0470J50-E SMD capacitor 47pF 0805 NPO 50V(RoHS) 1 C128,
25
ES250PW
