JBL ES250PW - Wireless Receiver PCB Components

Part Number Description Qty Reference Designator
INPUT/PREAMP PCB
141-B0680J50-E SMD capacitor 68pF 0805 NPO 50V(RoHS) 1 C127,
141-B5104Z50-E Capacitor CAP SMD 0805 Y5V0.1uF +80/-20% 50V LF 19
C320,C322,C112,C114,C116,C118,C124,C125,
C130,C232,C233,C153,C154,C184,C185,C206,
C205,C144,C145,
141-B7222K50-E SMD capacitor 2.2nF ±10% 50V 0805X7R (RoHS) 2 C181,C182,
141-B7272K50-E SMD capacitor 0805 2700PF 50V X7R(RoHS) 1 C110
141-B7332J50-E SMD capacitor 0805 X7R 3300pF 5%(RoHS) 2 C120,C317,
141-B7472J50-E SMD capacitor 0805 X7R 4700PF 5% 50V(RoHS) 1 C110A,
129-A104J633-E Capacitor 0.1U 63V ±5% MSC (RoHS) 1 C149,
129-A224J633-E Capacitor 0.22uF 63V ±5% MSC(RoHS) 2 C121,C122,
129-A333J633-E Capacitor 0.033U 63V MSC (RoHS) 2 C209,C218,
129-A473J633-E Capacitor 0.047U 63V ±5% MSC RoHS 1 C150,
129-A683J633-E Capacitor 0.068U 63V ±5% MSC RoHS 2 C201,C213,
135-3106M25-E Capacitor 10uF 25V ±20% (RoHS) 10
C310,C311,C109,C111,C123,C126,C129,C133,
C134,C141,
135-3107M16-E Capacitor 100uF 16V ±20% (RoHS) 16
C152,C159,C160,C327,C328,C155,C156,C113,
C115,C117,C119,C132,C157,C158,C329,C330,
135-3226M25-E Capacitor 85℃ 22uF ±20%25V LF 2 C312,C151,
139-3227M16-E Capacitor 220uF 16V±20% (RoHS) 1 C131,
Semiconductors
192-153J111-E FET J111 FAIRCHILD TO-92 (RoHS) 1 Q107,
190-16TL072DTS-E I.C. TL072N @6.5 (RoHS) DUAL OP-AMP 4 U109,U101,U103,U108,
190-16TL074CDS-E I.C TL074CN ST (RoHS) QUAD OP-AMP 2 U102,U106,
192-027C1815GRS-E SMT Transistor MMBT1815 SOT-23(RoHS) 5 Q402,Q403,Q101,Q102,Q103,
192-998A1015GRS-E SMD Transistor MMBT1015 CJ SOT-23(RoHS) 2 Q400,Q401,
197-0S4148WSP-E SMD diode LL4148WSP 0805SHAWELL 10
D303,D304,D400,D112,D113,D108,D109,D110,
D207,D208,
199-6200043D-E Zener diode 4.3V BZT52-C4V3SSOD-323(RoHS) 1 D130,
Miscellaneous
162-10169003-E WIRE 160mm AWG28 WHite/BK (RoHS) 1 P105,
162-5011D001-E WIRE 110mm P=2.54mm(RoHS) 1 D401,
162-8008D001-E WIRE 80mm 4pin P=2.0mm(RoHS) 1 P1,
174-0RCA313G-E RCA Jack RCA-313G (RoHS) 1 JK1,
175-1C02V01-E Connector 2PIN PITCH=2.5mm (RoHS) 1 P106,
180-T000TS81-E TACT SWITCH L101 T2 T8019L-SNQ-E-H+U PHASE/LO P
A
2 SW103,SW105,
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 1 BK2,
EQ DAUGHTER BOARD PCB
110-16000J26-E Resistor 0Ω 1/6W ±5% CF 26mm (RoHS) 1 R191,
116-161001F26-E Resistor 1K 1/6W ±1% MF26mm (RoHS) 1 R252,
116-161373F26-E Resistor 137k 1/6w ±1% MF(RoHS) 1 R190,
116-161431F26-E Resistor 1.43K 1/6W ±1%MF(RoHS) 1 R251,
116-161542F26-E Resistor 1/6W 15.4K 1% 26mm (RoHS) 2 R173,R178,
116-162372F26-E Resistor 23.7K 1/6W 1% MF(RoHS) 1 R188,
116-163741F26-E Resistor 3.74K 1/6W ±1% MF(RoHS) 1 R253,
116-168251F26-E Resistor 8.25K 1/6W ±1% MF26mm (RoHS) 1 R189,
129-A104J633-E Capacitor 0.1U 63V ±5% MSC (RoHS) 1 C137,
129-A273J633-E Capacitor 0.027uF 63v ±5% MSC (RoHS) 1 C142,
129-A473J633-E Capacitor 0.047U 63V ±5% MSC (RoHS) 1 C138,
129-A683J633-E Capacitor 0.068U 63V ±5% MSC (RoHS) 1 C143,
130-3F104Z503-E Capacitor 0.1U 50V +80/-20% (RoHS) 2 C144,C145,
175-9F08HR2-E Connector 8PIN PITCH=2.54mm(RoHS) 1 P104,
190-16TL072N-E I.C. TL072N @6.5 (RoHS) DUAL OP-AMP 1 U105,
26
ES250PW
