JBL ES250PW - Class D PCB Assembly Components

Part Number Description Qty Reference Designator
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
Resistors
112-10180J00-E Resistor FMF 1W 18Ω 5%(RoHS) 1 R47
118-12061001F-E SMD Resistor 1K 1206 1% (RoHS) 1 R2,
118-12061002F-E SMD Resistor 10K 1206 1% (RoHS) 1 R25,
118-12061002J-E SMD Resistor 10.0K 1206 5% (RoHS) 5 R29,R30,R30B,R7,R9,
118-120610R0J-E SMD Resistor 10.0Ω 1206 5% (RoHS) 4 R20,R20B,R22,R23,
118-12062002F-E SMD Resistor 20K 1206 1% (RoHS) 1 R26,
118-12062201J-E SMD Resistor 2.20K 1206 5% (RoHS) 18
R13,R16,R31,R33,R34,R35,R36,R37,R38,R39,
R40,R41,R42,R43,R44,R45,R46,R32,
118-12062204J-E SMD Resistor 2.20M 1206 5% (RoHS) 1 R4,
118-12062211F-E SMD Resistor 2.21K 1206 1% (RoHS) 1 R6,
118-12062550F-E SMD Resistor 1206 255Ω 1% (RoHS) 1 R24,
118-12062701J-E SMD Resistor 2.70K 1206 5% (RoHS) 1 R10,
118-12063301J-E SMD Resistor 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28,
118-12063321F-E SMD Resistor 3.32K 1206 1% (RoHS) 1 R1,
118-12063922F-E SMD Resistor 1206 39.2K±1% (RoHS) 1 R3,
118-12064700J-E SMD Resistor 470Ω 1206 5% (RoHS) 3 R8,R11,R21,
118-12064701J-E SMD Resistor 4.7K 5% 1206(RoHS) 1 R12,
118-12064751F-E SMD Resistor 4.75K 1206 1% (RoHS) 1 R5,
Capacitors
128-E106MA01-SE Capacitor 10uF 100V 20%(RoHS) 2 C16,C17,
129-A104JA03-E Capacitor 0.1U 100V ±5% MSC (RoHS) 2 C12B,C14,
130-SL681KB03-E Capacitor SL 680PF 200V (RoHS) 1 C21
132-104KB50-E Capacitor 0.1U ±10% 250V (RoHS) 1 C20,
132-105KB50-E Capacitor 1uF 250V ±10% (RoHS) 1 C40,
141-C0101K50-E SMD capacitor 100pF 50V 10%1206 NP0 (RoHS) 1 C4,
141-C0220K50-E SMD capacitor 22pF 50V 10% 1206SMT NPO (RoHS) 1 C5,
141-C0561K50-E SMD capacitor 560pF 50V 10%1206 NPO (RoHS) 1 C6,
141-C5104M50-E SMD capacitor 1206 Y5V 0.1uF50V ±20% (RoHS) 8 C2,C3,C7,C8,C9,C10,C11,C15,
141-C7103K50-E SMD capacitor 10nF 50V 1%1206 X7R (RoHS) 1 C13,
141-D7104KB5-E SMD capacitor 0.1uF 250V 10%1210 X7R (RoHS) 2 C18,C19,
Semiconductors
192-1582N5401-E Transistor FSC 2N5401 AI-PNP 350V500mA TO-92 (RoHS) 1 Q6B,
192-232IRF9640-E FET IRF9640 IR P-CH TO220(RoHS) 2 Q10,Q10B,
192-233F640N-E Transistor IRF640N INTERNATIONAL(RoHS) 1 Q11,
190-16tl072dts-e
SMD I.C. TL072CDT SGS THOMSON(RoHS) DUAL OP-AMP 1 IC1,
192-09124126qs-e SMD transistor 2SC2412K-T146Q/RROHM (RoHS) 2 Q1,Q4,
192-09139066rs-e SMD transistor 2SC3906K-T146R ROHM(RoHS) 2 Q2,Q8,
192-091SC4672-E Transistor 2SC4672(MPT3) ROHM(RoHS) 1 Q5B,
192-09210376qs-e SMD transistor 2SA1037K-T146Q/RROHM (RoHS) 2 Q7,Q9,
192-09215146rs-e SMD transistor 2SA1514K-T146R ROHM(RoHS) 1 Q3,
197-03rls4148s-e SMD diode RLS4148-TE11 ROHM(RoHS) 8 D1,D2,D3,D4,D5,D5B,D6,D20,
199-15000563S-E SMD ZENER 5.6V 5% PHILIPSBZX84-C5V6(RoHS) 2 Z1,Z2,
199-1500120s-e SMD ZENER 12V 5% PHILIPSBZX84-C12 (RoHS) 4 Z3,Z4,Z5,Z6,
Miscellaneous
175-9F02H02-E Connector 2PIN PITCH=2.54mm(RoHS) 1 HDR3,
175-9F03H020-E Connector 3PIN PITCH=2.54mm(RoHS) 2 HDR1,HDR2,
359-FIB-00125-E Gasket 10*5*0.5T (RoHS) 2
122-13151K0190-E CHOKE SA-500-280(PT1601B*151MAA) (RoHS) 1 L1,
122-14300K4-E Ferrite core LD1215*300KU±10% RoHS 1 L2,
WIRELESS RECEIVER PCB
Resistors
118-08050000J-E SMD Resistor 0805 1/10W 0Ω±5%LF 8 R21,R27,R28,R29,R30,R36,R37,R22,
27
ES250PW
