Part Number Description Qty Reference Designator
WIRELESS RECEIVER PCB
118-08051002J-E SMD Resistor 0805 1/10W 10KΩ ±5%LF 3 R26,R12,R13,
118-08051200F-E SMD Resistor 120Ω 0805 1% RoHS 1 R503,
118-08052002J-E SMD Resistor 20K 0805 1/10W 5%(RoHS) 15
R04,R05,R06,R07,R08,R09,R10,R11,R14,R15,
R16,R17,R18,R19,R20,
118-08052400F-E SMD Resistor 240Ω0805 1% ROHS 1 R504,
118-08052703J-E SMD Resistor 270K 0805 5% (RoHS) 1 R502,
118-08053303J-E SMD Resistor 330K 0805 5% (RoHS) 1 R501,
118-08054701J-E SMD Resistor 0805 1/10W 4.7K ±5%LF 1 R38,
118-08054702J-E SMD Resistor 47K 0805 1/10W 5%(RoHS) 1 R03,
118-08054R70J-E SMD Resistor 4R7 0805 1/10W 5%(RoHS) 2 R01,R02,
118-080556R0J-E SMD Resistor 0805 56Ω 1/10W 5%(RoHS) 1 L01,
118-08056200J-E SMD Resistor 0805 620Ω ±5% (RoHS) 2 R39,R40,
116-1410R0J5VX-E Resistor 10Ω 1/4W ±5% (RoHS) 1 R505,
Capacitors
141-B7104K50-E Capacitor CAP SMD 0805 X7R0.1uF ±10% 50V LF/RoHS 10 C02,C05,C08,C09,C10,C14,C16,C504,C507,C5
141-B7332J50-E SMD capacitor 0805 X7R 3300pF 5%(RoHS) 2 C20,C21,
142-AV107M16H-E SMD capacitor 100UF 16V φ6.3*5.4mm (RoHS) 1 C11,
141-B7102J50-E SMD capacitor 0805 X7R 1nF 50V5% (RoHS) 1 C06,
141-B7103K50-E SMDcapacitor 0.01U 50V X7R 0805(RoHS) 2 C03,C505,
142-SV105M50H-E SMD capacitor 1uF 50V 4.3*4.3mm(RoHS) 2 C15,C17,
142-SV106M16H-E SMD capacitor 10U 16V (RoHS) 3 C12,C13,C18,
130-2B104KA03-E capacitor 0.1uf 100V 10% (RoHS) 1 C503,
135-3476M100-E Capacitor 47uF 100V±20% 10*16 5mm (RoHS) 1 C501,
135-3477M16-E Capacitor 85℃ 470uF ±20%16V LF 4 C01,C04,C511,C506,
Semiconductors
190-145008MMS-E
SMD IC LM5008MM/NOPB(NATIONAL)(RoHS) High Voltage
(100V) Step Down Switching Regulator
1 U501,
190-19HCT165S-E
SMD IC 74HC/HCT165(RoHS)PHILIPS 8-bit parallel-in/serial-
out shift register
2 U02,U03,
190-99CS4340KS-E IC CS4340-KS 16Pin SoIC(RoHS) 24-Bit, 96 kHz Stereo DAC 1 U04,
190-99IMP809S-E SMD IC IMP809SEUR-T(IMP)(RoHS) RESET 1 U01,
051-WH4927-E Wireless HI-FI Audio RX ModuleWH4927 (RoHS) 1 MD01
197-63S110-E Diode S100 100V 1A SMAD0-214AC(RoHS) 1 D501,
Miscellaneous
162-5009D006-E Wire 90mm P=2.0mm(RoHS) 1
180-SS14H03GT-E SLIDE SW SS14H03GT-GP(RoHS) Wireless ID Code 1,2,3,4 1 SW01,
121-COMM220M-E SMD inductor 22UH±20%YC5D18T*220MS(RoHS) 1 L502,
121-COMM221M-E SMD inductor 220UH±20% YC8D43T*221MS(RoHS) 1 L501,
175-1B04V01A-E Connector 4PIN PITCH2.0mm (RoHS) 1 P1,
175-1C02V01-E Connector 2PIN PITCH=2.5mm (RoHS) 1 P501,
175-9B06V03-E Connector 6Pin PITCH=2.0mm(RoHS) 1 for SW01,
175-9Y25V2201-E PIN HEADER 25PH=1.27mm(RoHS) 1
333-EVA-05425-0BAE EVA 13*10*3MM CONTROL 2.4G (RoHS) 2
362-FE-00041-0LAE PCB stand 11.75*8.5*12.5H(RoHS) 2 BK01,BK02,
EMI/FUSE PCB
122-14103M4200-E Inductor RT251510*103N 10mH (RoHS) 1 L02
122-14501M0650-E Inductor 0.5mH ψ0.65 (RoHS) 1 L01,
130-3F102MB50-E Capacitor Y1 1NF 20% 250V (RoHS) 2 C03,C04,
132-334KB70-E Capacitor 0.33U 275V +/-10% (RoHS) 1 C02,
132-334KB74-E Capacitor 0.33uF 275V +/-10% LS=15mmRoHS) 1 C01,
162-10090003-E Wire 90mm20AW#187t0.51617 (RoHS) 1
162-10099003-E Wire 90mm20AWG#187t0.51617 (RoHS) 1
154-K31505T0-E Fuse 3.15A 250V 30mm UL/CSA/PSE (RoHS) 1
155-630R345B-E Fuse holder UL/CSA 6*30mm R3-45B (RoHS) 1
ES250PW
To Next Page
