Mode Adjust JBL Performance
5-28
5.1a BYPASS
• Designed for playback of 5.1-channel analog sources, such as
DVD-A or SACD players.
• The 5.1-channel analog input connectors are sent directly to
the volume control and audio output connectors as shown on
page 3-49. These signals receive no internal processing.
• When both side and rear speakers are present, surround
channel signals are sent in parallel to the side and rear speak-
ers. To configure a 5-channel speaker setup, set the OUTPUT
lEVELS menu SIDE L/R or REAR L/R parameter to OFF to deac-
tivate the associated surround speakers.
• The 5.1a BYPASS listening mode is automatically activated
whenever one of the 5.1-channel analog audio input connec-
tors is assigned to the selected input.
• The 5.1a BYPASS listening mode is the only listening mode
available for 5.1-channel analog sources.
See “Listening Mode Menu Option & Parameter Descriptions” on page 5-29 for detailed
descriptions
.
Note:
Speaker crossover settings, speaker distances and audio (tone) controls
are not available when the 5.1a BYPASS listening mode is activated.
2CH BYPASS
• Designed for playback of 2-channel analog sources.
• Analog audio input signals are sent to the audio output con-
nectors labeled Front L/R. These input signals receive no inter-
nal processing.
• The 2CH BYPASS listening mode is automatically activated
when a 2-channel analog audio source is present and the
ADVANCED menu 2-CH ANLG BYP parameter is set to ON.
• the 2CH BYPASS listening mode is not available when the
ADVANCED menu INPUT SELECT parameter is set to AUTO
and a digital audio source is present.
• No parameters are available for the 2CH BYPASS listening
mode.
Note:
Speaker crossover settings, speaker distances and audio (tone) con-
trols are not available when the 2CH BYPASS listening mode is acti-
vated.
Option/Parameter
OUTPUT LEVELS --
CUSTOM --
5.1a BYPASS
MODE ADJUST
2CH BYPASS
MODE ADJUST
