Basic Operation JBL Performance
2-2
FRONT-PANEL OVERVIEW
The numbers in the front-panel illustration correspond with the numbered items below.
1 STANDBY BUTTON
Use the Standby button to activate or deactivate standby mode.
The Standby button performs no function when the AV1 is pow-
ered off with the rear panel power switch.
When in standby mode, pressing the Standby button activates the
AV1. When standby mode is deactivated, pressing the Standby but-
ton activates standby mode and deactivates the AV1. The red
standby button LED lights indicating that standby mode is acti-
vated.
2 FRONT-PANEL DISPLAY
Use the Front-Panel display to view the current input, listening
mode, input source and volume level. The 2 x 20 character display
also functions as a display for messages and menus. See “Menu
Navigation” on page 2-6 for more information.
1
2
3
4
6
57
