SPECIFICATIONS
Audio Input & Output Connectors
Analog Audio Inputs 8 stereo (RCA) or 5 stereo and one 5.1-channel or 2 stereo
and two 5.1-channel connectors
Digital Audio Inputs • 4 S/PDIF coaxial (RCA) and 4 S/PDIF optical (TosLink)
connectors
• Coaxial and optical input connectors conform to IEC-
958, S/PDIF standards
• Accepts 44.1, 48, 88.2 and 96kHz sample rates
• Accepts 16-24 bits PCM audio, Dolby Digital, DTS and
DTS-ES discrete data formats
Audio Outputs 8 unbalanced (RCA) connectors for Front L/R, Center,
Subwoofer, Side L/R, and Rear L/R
Audio Performance
A/D Conversion 24-bit, 96kHz, dual-bit ∆Σ architecture
D/A Conversion 24-bit, 44.1 to 192kHz, multi-bit ∆Σ architecture
Frequency Response 10Hz to 20kHz, +0.05dB/-0.1dB, -0.5dB at 40kHz, reference
1kHz
THD + Noise Below 0.008% at 1kHz, maximum output level
Dynamic Range 108dB minimum, 22kHz bandwidth
Signal-to-Noise Ratio 108dB minimum, 22kHz bandwidth
Input Sensitivity 200mVrms (2Vrms for maximum output level) at 0dB input
gain
Input Impedance 100kΩ in parallel with 150pF
Output Level • 150mVrms typical, 6Vrms maximum
• Maximum value with full-scale input signal and volume at
+12dB
Output Impedance
100
Ω in parallel with 150pF
Video Input & Output Connectors
Video Inputs 5 composite (RCA), 5 S-video, and 3 component video (RCA)
Video Outputs 1 composite (RCA), 1 S-video, and 1 component (RCA)
Composite & S-video Performance
Compatibility NTSC, PAL, and SECAM
Switching Active
Output Level 1.0V peak-to-peak
Impedance
75Ω
Input Return Loss >40dB
Differential Gain <0.5%
Differential Phase <0.5°
Bandwidth >25MHz
K Factor <0.3%
Gain ±0.15dB
Signal-to-Noise Ratio >65dB
Frequency Response 10Hz to 10MHz + 0.1/-0.3dB
