Setup JBL Performance
3-44
5 ST. & (1) 5.1 ANLG (continued)
When the analog audio input connectors are configured as five
stereo and one 5.1-channel connectors:
Two-channel sources assigned to the stereo connectors are reas-
signed to the corresponding 5.1-channel connectors. The 5.1-
channel connectors should only be used with 5.1-channel analog
sources such as DVD-As and SACDs.
2 ST. & (2) 5.1 ANLG
Configures the analog audio input connectors as two stereo and
two 5.1-channel connectors.
When the analog audio input connectors are configured as two
stereo and two 5.1-channel connectors:
• The connectors labeled 1 and 2 are configured as stereo connectors.
• The connectors labeled 3, 4 and 5 are configured as a 5.1-channel
connector, and the connectors labeled 6, 7 and 8 are configured
as a 5.1-channel connector. These connectors are sent to the
audio output connectors as indicated in the table below.
• Two-channel sources assigned to the stereo connectors are
reassigned to the corresponding 5.1-channel connectors. The
5.1-channel connectors should only be used with 5.1-channel
analog sources such as DVD-As and SACDs.
The 5.1-channel analog audio input connector is sent to the
analog audio output connectors as shown in the table below.
REAR PANEL CONFIG
SETUP
5 ST. & (1) 5.1 ANLG
Input Connector Output Connector
(L) Front L
(R) Front R
(C) Center
(SUB) Subwoofer
(LS) Side L and Rear L
(RS) Side R and Rear R
REAR PANEL CONFIG
SETUP
2 ST. & (2) 5.1 ANLG
