Amplifier/Subwoofer PSW-D112/DPS-12
3. Low-Pass
-Set up Set Generator at 100mV@100Hz
Signal to Low level input
Measure voltage at speaker output
-Voltage measurement
Low-Pass Pot Setting Output
CW 12.2V
CCW 1.2V
4. High-Pass
-Set up Set Generator at 100mV@100Hz
Signal to Low level input
Measure voltage at high-pass output
-Voltage measurement
High-Pass Pot Setting Output
CW 24mV
CCW 55mV
5. Direct out
-Set up Set Generator at 100mV@100Hz
Signal to Low level input
-Voltage measurement 100mV at direct out
See flow chart next page for diagnostics.
