JBL PSW-D112 - ELECTRICAL PARTS LIST (Rev0)

PSW-D112/DPS-12 ELECTRICAL PARTS LIST (Rev0)
Preamp Board
Low Pass 40436 20kW 0.25W 10% Quad Lin Pot 1
Level 40402 5kW 0.25W 10% Single Linear Pot 1
High pass 40450 20kW 0.25W 10% 3-gang Tandem Lin Pot 1
Capacitors
Safety C1 30502 100nF 50V 20% Mono-ceramic axial 1
C2, C3 30501 47nF 50V 20% Mono-ceramic axial 2
CE3 30708 47uF 16V 20% Electrolytic Radial 1
C4 30501 47nF 50V 20% Mono-ceramic axial 1
C5 30100 330pF 50V 20% Mono-ceramic axial 1
C6, 24, 25 30501 47nF 50V 20% Mono-ceramic axial 3
C7, 9 30100 330pF 50V 20% Mono-ceramic axial 2
C8 30101 220pF 50V 20% Mono-ceramic axial 1
C10 30502 100nF 50V 20% Mono-ceramic axial 1
C11, 12 30517 68nF 50V 10% Mono-ceramic axial 2
C13, 14, 15 30101 220pF 50V 20% Mono-ceramic axial 3
C16 30504 100nF 50V 10% Mono-ceramic axial 1
C17 30502 100nF 50V 20% Mono-ceramic axial 1
C18 Jumper
C19 30508 10nF 50V 10% Mono-ceramic axial 1
C20, 21, 22, 23 30504 100nF 50V 10% Mono-ceramic axial 4
Resistors
R1 40405 4.7kW 0.25W 5% carbon film 1
R2 40431 68kW 0.25W 1% metal film 1
R3 40451 137kW 0.25W 1% metal film 1
R4 40452 2.7kW 0.25W 5% carbon film 1
R5, 6 40438 20kW 0.25W 1% metal film 2
R7 40108 620W 0.25W 5% carbon film 1
R8 40453 20kW 0.25W 5% carbon film 1
R9, 10, 13 40438 20kW 0.25W 1% metal film 3
R11, 12, 14 40108 620W 0.25W 5% carbon film 3
R15 40732 56.2kW 0.25W 1% metal film 1
R16 40743 7.5kW 0.25W 5% carbon film 1
R17, 18 40453 20kW 0.25W 5% carbon film 2
R19, 20 40108 620W 0.25W 5% carbon film 2
R21 40412 33.2kW 0.25W 1% metal film 1
R22 40454 45.3kW 0.25W 1% metal film 1
R23 40405 4.7kW 0.25W 1% metal film 1
R24 40408 8.45kW 0.25W 1% metal film 1
R25 40455 169kW 0.25W 1% metal film 1
R27 40434 38.3kW 0.25W 1% metal film 1
R28 40456 2.7kW 0.25W 5% carbon film 1
R32 40403 10kW 0.25W 1% metal film 1
R33, 34, 35, 36, 40440 6.8kW 0.25W 5% carbon film 5
49
R37, 38 40438 20kW 0.25W 1% metal film 2
R42 40457 200kW 0.25W 5% carbon film 1
R43 Jumper
R45 40449 3.3kW 0.25W 5% carbon film 1
R46, 47 40415 470kW 0.25W 5% carbon film 2
R48 40742 4.99kW 0.25W 1% metal film 1
Diodes
Signal LED 50109 Bi-colour 1
Video LED 50110 Green 1
Transistors
TR1 60154 MPS A56 80V PNP 1
TR2 60151 MPS A13 40V NPN(Darl) 1
Integrated Circuit
U1 , U2 60100 LM324 Dual OpAmp +/-15V 2
U3 60101 TLO 82 Dual OpAmp +/-15V 1
Poweramp Board
Capacitors
C1 , C2 30710 2200uF 100V 80/-20% Electrolytic radial 2
C3 , C4, C5 30505 100nF 50V 20% mono-ceramic axial 3
C4, 5 30505 100nF 50V 20% mono-ceramic axial 2
C6 30709 4.7uF 100V 80/-20% Electrolytic radial NP 1
C7a/b 30521 100nF 250V 20% Metal Polyester Rad 2
C8 30502 100nF 50V 20% mono-ceramic axial 1
C21 30522 100nF 250V 20% mono-ceramic axil 1
C24 30523 330nF 100V 80/-20% mono-ceramic axial 1
C26 30508 10nF 50V 10% mono-ceramic axial 1
C27 30513 3.3nF 50V 10% mono-ceramic axial 1
C29 30711 22uF 35V 80/-20% Electrolytic radial 1
C31 30511 330nF 50V 20% mono-ceramic axial 1
CW, CZ 30505 100nF 100V 20% mono-ceramic axial 2
Diodes
D1 50114 1N5265B 62V 5% .5W Zener 1
D2, 4 50104 1N4148 100V .1A 2
D6 50103 1N5234B 6.2V 5% .5W Zener 1
D9, D10 50105 1N4744A 15V 5% 1W Zener 2
DBR 50100 Bridge Rect 200V 4A 1
Semiconductors
Q3 60153 2N3904 40V NPN 1
Q4, Q5 60155 2N5401 PNP 2
U4 60101 TL082 Dual Op Amp 1
S64AMI 60302 Power Amp module SAFETY PART 1
25
Amplifier/Subwoofer PSW-D112/DPS-12
Ref. # Part Number Description Qty Ref. # Part Number Description Qty
