Resistors
R1 40706 10M 0.25W 5% carbon film 1
R3 40458 43.2k 0.25W 1% metal film 1
R4 40417 47k 0.25W 5% carbon film 1
R4a/b/c 40105 0.1 0.5W 5% metal film 3
R5, 6 40420 1k 0.25W 5% carbon film 2
R7 40449 3.3k 0.25W 5% carbon film 1
R8, 25 40417 47k 0.25W 5% carbon film 2
R9 40744 3.3k 5W 5% ceramic wirewound 1
R14 40409 10k 0.25W 5% carbon film 1
R15 40459 100k 0.5W 5% carbon film 1
R16, 17 40745 1.8k 7W 5% ceramic wirewound 2
R23 40461 20k 0.5W 5% carbon film 1
R24 40418 22k 0.25W 5% carbon film 1
R33, 50 40100 332 0.5W 5% carbon film 2
R46 40111 47 ohms 0.25W 5% carbon film 1
R49 40746 316k 0.25W 1% metal film 1
R51 40417 47k 0.25W 5% carbon film 1
R52, R57 40462 2.7k 5W 5% ceramic wirewound 2
R58, 59 40405 4.7k 0.25W 5% carbon film 2
R60 40431 68k 0.25W 5% carbon film 1
R61 40463 3.9k 3W 5% ceramic wirewound 1
SafetyInductors
CMC1 80100 mc4438 1
L1 80121 mc4642 1
“L2,L3,L4" 80122 Ferrite Bead 3
High Level Input/OutputBoard
Capacitors
C1 30704 220uF 50V 20% Electrolytic Radial 1
C2 30704 220uF 50V 20% Electrolytic Radial 1
C3 30704 220uF 50V 20% Electrolytic Radial 1
Resistors
R1 L, R3 L, 40406 100k 0.25W 5% carbon film 6
R1 C, R3 C,
R1 R, R3 R
R2 L, R2 C, R2 R 40405 4.7k 0.25W 5% carbon film 3
Miscellaneous
1 70302 Knob, 3 pcs on DPS-12, 2 pcs on PSW-D112
2 70312 Faceplate PSW-D112
2 70311 Faceplate DPS-12
3 70316 Amp PCB support
4 70150 Phase switch 1
(also DPS-12 Video Contour switch)
5 70151 Power switch Safety part
6 70170 #4x0.5" Screws to secure input jack
7 70171 #10 x 1" Screw machine screw
Bolts for transformer 4 per unit
8 70172 #10 keps Nuts for transformer 4 per unit 4
9 70173 #6 x 0.5" Screws for fuse PCB 2per unit 2
10 80116 Transformer #4632 Safety part 1
11 80117 250V, 2.0A, T type SLO BLO fuse Safety part
12 80118 Preamp board, D112,D115,DPS12 Safety part
13 80119 Power amp board D112, D115,DPS12
Safety part
14 80120 High level input PCB D112,D115,DPS12
Safety part
15 108116 High level 5way binding post(pr) (4) or (6)
16 108322 Six line RCA input jack 1
17 108323 Single RCA input jack (Rev0 version only) 1
Revisions
Date Issue Details
18/11/98 2 “R23(20k,.25W) to 3.9k 3W, U3 added”
19/11/98 3 “U2 changed to U4, D1(90V) to 62V,”
11/26/1998 4 “R61A added, R24(8.66k) to 8.45k”
12/1/1998 5 “R15(39k) to 38.3k, R18/R15A added,
R42(330k) to 200k)”
1/20/1999 7 “R20(1%MF) to 5%CF, R15A(.5W) to .25W”
2/22/1999 9 “R46(1000k) to 470k, C21/CW/CZ changed
to poly film”
6/8/1999 10 “R16/R17(2.4k,5W) to 1.8k, 5W. 2.4k (5W) can
be used with 6.8, 3W metal oxide in parallel”
9/2/1999 11 “R16(4.7k) to 7.5k. C3(47n) to 100n, R9(3.9k) to
3.3k, R61(5.1k,2W) to 3.9k,3W. PCB now rev 3.2"
26
Amplifier/Subwoofer PSW-D112/DPS-12
Ref.# PartNumber Description Qty Ref.# PartNumber Description Qty
