Preamp Board
Capacitors
C1, 2 30707/04 200uF 200 radial 50V 0.2 BP Electrolytic 2
C3, 4, 5, 6 30101 220pF 400 axial 50V 0.2 mono ceramic 4
C7 0.0R Jumper 400 axial 50V 1
C8, 9 30517 68n 400 axial 50V 0.05 mono ceramic 2
C10, 11, 12, 13 30504 100nF 400 axial 50V 0.1 mono ceramic 4
C14, 15, 16, 17 30514 47nF 400 axial 50V 0.1 mono ceramic 4
C18, 19 30100 330pF 400 axial 50V 0.2 mono ceramic 2
C20, 21, 22, 23 30502/04 100nF 400 axial 50V 0.2 mono ceramic 4
Integrated Circuits
U1 60100 LM324 DIP14 Quad OpAmp 1
U2 60102 TLO 64 DIP14 Low Power Quad OpAmp 1
Resistors
R1, 2 40405 4.7kW 400 axial .25W 0.05 carbon 2
R3, 4, 5, 6 40406 100kW 400 axial .25W 0.05 carbon 4
R8, 9 40452 2.7kW 400 axial .25W 0.05 carbon 2
R10 40453 20kW 400 axial .25W 0.05 carbon 1
R11 40749 75kW 400 axial .25W 0.05 carbon 1
R12 40504 45.3kW 400 axial .25W 0.01 metal 1
R13 40412 33.2kW 400 axial .25W 0.01 metal 1
R14 40709 68.1kW 400 axial .25W 0.01 metal 1
R16 40434 38.3kW 400 axial .25W 0.01 metal 1
R17 40455 169kW 400 axial .25W 0.01 metal 1
R18, 19, 20, 22 40722 6.8kW 400 axial .25W 0.05 carbon 4
R24, 26, 27, 30 40109 604W 400 axial .25W 0.01 metal 4
R25, 28, 31, 32 40438 20kW 400 axial .25W 0.01 metal 6
33, 34
R35 40451 137kW 400 axial .25W 0.01 metal 1
Miscellaneous
Level 40402 5kW Single Pot on harness 0.2 LOG 1
Remote n/a Molex Connector 100 3pin female 1
LoPass control 40707 20kW 4 gang Pot 0.2 1
Linear HiPass 40707 20kW 4 gang Pot 0.2 1
control
Phase Switch 70150 SW SPDT In Line 1
RCA CONN. 108321 Quad Right Angle Quad RCA 1
J1, 3 0.0W Jumper 400 axial .25W 2
28
Amplifier/Subwoofer PSW-D112/DPS-12
