JBL PX300.4 - Page 11

ELC-00-00116 CAPACITOR ELECTROLYTIC "SE" 2.2uF/50V
2
C801,802
ELC-00-00626 CAPACITOR ELECTROLYTIC "SE" 10uF/50V
1
C62
ELC-00-00160 CAPACITOR ELECTROLYTIC "SG" "SMS" 4.7uF/50V
10
C103,107,131,203,207,231,307,331,431,407
ELC-00-00125 CAPACITOR ELECTROLYTIC "SG" "SMS" 10uF/16V
1
C12
ELC-00-00137 CAPACITOR ELECTROLYTIC "SG" "SMS" 10uF/25V
1
C7
ELC-00-00127 CAPACITOR ELECTROLYTIC "SG" "SMS" 22uF/16V
8
C101,102,201,202,301,302,401,402
ELC-00-00130 CAPACITOR ELECTROLYTIC "SG" "SMS" 47uF/16V
3
C3,8.15
ELC-00-00159 CAPACITOR ELECTROLYTIC "SG" "SMS" 47uF/50V
4
C55,65,75,85
ELC-00-00523 CAPACITOR ELECTROLYTIC "SG" "SMS" 100uF/16V
8
C1,2 ,5,142,171,271,371,471
ELC-00-00254 CAPACITOR ELECTROLYTIC "SXE" 100uF/25V
1
C9
ELC-00-00133 CAPACITOR ELECTROLYTIC "SG" "SMS" 330uF/16V
4
C191,291,391,491
CEC-00-00077 CAPACITOR CERAMIC DISK 50V "NPO" 10pF
4
C105,205,305,405
CEC-00-00090 CAPACITOR CERAMIC DISK 50V "NPO" 22pF
5
C61,170,270,370,470
CEC-00-00093 CAPACITOR CERAMIC DISK 50V "NPO" 27pF
2
C208,408
CEC-00-00103 CAPACITOR CERAMIC DISK 50V "NPO" 47pF
8
C109,112,209,212,309,312,409,412
CEC-00-00105 CAPACITOR CERAMIC DISK 50V "NPO" 56pF
2
C108,308
CEC-00-00108 CAPACITOR CERAMIC DISK 50V "NPO" 68pF
4
C132,232,332,432
CEC-00-00073 CAPACITOR CERAMIC DISK 50V "NPO" 100pF
12
C134
,141,144,234,241,244,334,341,344,434
C441,444
CEO-00-00075 CAPACITOR CERAMIC DISK 50V "NPO" 103pF
1
C21
CEC-00-00102 CAPACITOR CERAMIC DISK 50V 473pF
2
C23,24
CEC-00-00076 CAPACITOR CERAMIC DISK 50V 104pF
19
C4,6,14,25,39,701,702,703,704,705
C706,707,708,709,710,711,712,713,714
CEO-00-00074 CAPACITOR CERAMIC DISK 50V "NPO" 102pF
4
C100,200,300,400
MYC-00-00184 CAPACITOR MYLAR 5% 100V 102J
1
C17
MYC-00-00186 CAPACITOR MYLAR 5% 100V 222J
2
C16,18
MYC-00-00183 CAPACITOR MYLAR 5% 100V 104J
4
C161,261,361,461
MYC-00-00090 CAPACITOR MYLAR 63V "TL" 473J
4
C135,235,335,435
MYC-00-00157 CAPACITOR MYLAR 63V "TL" 823J
16
C110,111,113,114,210,211,213,214 ,310,311
C313,314,410,411,413,414
MYC-00-00083 CAPACITOR MYLAR 63V "TL" 104J
1
C26
MYC-00-00156 CAPACITOR MYLAR 63V "TL" 184J
2
C316,416
MYC-00-00066 CAPACITOR MYLAR 63V "TL" 474J
2
C315,415
MYC-00-00085 CAPACITOR MYLAR 63V "TL" 105J
2
C13.29
-
MAIN PCB
-
ICO-00-00022 I.C PWM IC "DIP 14" TL494CN
1
U
1
ICO-00-00109 I.C QUAD OP AMP "DIP 14" NJM2058D
8
U101,102,103,104,105,108,109,110
ICO-00-00003 I.C DUAL OP AMP "DIP 08" TL072
4
U111,112,113,114
ICO-00-00095 I.C DUAL COMPARATOR "DIP08" KIA393P
1
U801
TRS-00-00089 TRANSISTOR VIDEO TR PNP KSA1220
4
Q144,244,344,444
TRS-00-00106 TRANSISTOR VIDEO TR NPN KSC2690
4
Q134,234,334,434
TRS-00-00030 TRANSISTOR AUDIO POWER NPN 2SC4468
4
Q135,235,335,435
TRS-00-00024 TRANSISTOR AUDIO POWER PNP 2SA1695
4
Q145,245,345,445
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR
4
Q130.230.330,430
FET-00-00034 F.E.T N-CH MOSFET FQP50N06 "TO-220"
8
Q7,8,9,10,17,18,19,20
DIO-00-00048 DIODE FAST RECOVERY 1N5404
1
D
7
DIO-00-00152 DIODE FAST RECOVERY YG225D2
4
D5,6,11,12
DIO-00-00277 LED 3 PHI RED LED HNRD-3401L
1
LED1
DIO-00-00243 LED 3 PHI BLUE LED HL-304H1BC2
1
LED2
DIO-00-00279 LED 3 PHI TWO COLOR LED LT6G62-D7-D63
1
LED801
RES-00-00853 RESISTOR MOR-S 2WJ 2.2K OHM
2
R40,41
RES-00-01077 RESISTOR
MOR-S 2WJ "FORMING TYPE 20m
m
100 OHM
2
R30,32
RES-00-01044 RESISTOR
MOR-S 2WJ "FORMING TYPE 15mm
680 OHM
4
R162,262,362,462
RES-00-01043 RESISTOR
MOR-S 2WJ "FORMING TYPE 15mm
470 OHM
4
R191,291,391,491
RES-00-01029 RESISTOR
WIRE WOUND 7WJ
(25m/m)
0.1 OHM
8
R152,153,252,253,352,353,452,453
THS-00-00013 THERMISTOR 50K FTD5-350
1
T
H
VOL-00-00190 VOLUME V12L5(9X5)G(PH2D)N17KC 3B20K X 2
2
VR101,201
VOL-00-00281 VOLUME V12L5(9X5)G(8R)(PH2D)N15KC 50K x 8
2
VR102,202
VOL-00-00282 VOLUME V12L5(9x5)G(4R)(PH2D)N15KC 15A2K x 2, 15A200K
x
2
1
VR301
VOL-00-00283 VOLUME V12L5(9X5)G(PH2D)N17KC B500 x 2
1
VR302
