Ref# Description Part Number Qty
01 HEAT SINK MAIN AL/EXTRUSION (L=430mm) HEA-01-574A0 1
02 FRONT PANEL EGI 1.2T PAN-06-561A0 1
03 REAR PANEL EGI 1.2T PAN-06-564A0 1
04 WINDOW ACRYLIC 4.0T COV-22-623B0 1
05 BADGE AL BAD-01-515A0 1
06 MOUNTING FOOT ADC-7 DIE CASTING FOO-01-504B0 2
07 LENS, ACRYLIC (WITH SILKSCREEN) COV-22-549AA 1
LENS, ACRYLIC (WITHOUT SILKSCREEN) COV-22-549A0 1
08 INDICATOR ACRYLIC (CLEAR) ILL-22-503A0 3
09 BRACKET TR(A) CR,91 X 15 X 1.5T (NI-P) BKT-05-521A0 2
10 BRACKET TR(B) CR,103 X 15 X 1.5T (NI-P) BKT-05-521A0 2
11 CUSHION BKT-TR(A) FIBER 87 X 15 X 0.5T SUB-28-573A0 2
12 CUSHION BKT-TR(B) FIBER 99 X 15 X 0.5T SUB-28-574A0 2
13 CUSHION RUBBER (A) 12 X 7 X 1.6T SUB-33-513A0 5
14 SILICON PAD (SP1000) 22 X 0.3T SIL-34-001A0
15 SUPPORT PCB NYLON L=4.5mm SUP-29-502A0 6
16 SWITCH DECAL FELT 12 X 7 X 0.3T SUB-27-524A0 6
17 TUBE 5 X 40mm SUB-12-576A0 3
18 SCREW STT2 BH 3 X 12 NI-P SC5-NB-30120 6
19 SCREW STT2 BH 3 X 8 BK SC5-BB-30080 17
20 SCREW SML 3 X 6 NI (NO SERRATION) SC1-NL-30060 8
21 SCREW SML 4 X 10 NI-P SC1-NL-40100 10
22 SCREW STT1 PH 4 X 25 BK SC4-BP-40250 12
