Part number Description Qty Reference Designator
PREAMP PCB
195-10204hgw-e double color LED 204HGW 3￠(RoHS)
1
D209,
Miscellaneous
162-50062001-e 2PIN 60mm red/black
1
for D209,
174-0rca326p-e JACK RCA-326 (RoHS)
1
JK201,
174-2wp810a-e
SPK JACK 8P red up black down with cap 1
JK203,
175-1c07v01-e wire connector &base7PIN PITCH=2.5mm (RoHS)
1
P201,
180-tsv6201-e switch 6PIN DC30V 0.3V AUTO-ON, PHASE
2
SW1,SW201
MAIN PCB
Resistors
110-20332jk3-e
Resistor 3.3K 2W ±5% portrait short foot7.5m(RoHS)
1
R134
113-50s68j00-e
Resistor 0.068Ω 5W ±5% landscape short foot(RoHS)
1
R14
7
116-201001jk3x-e Metal Film Resistor 1.00K 2W ±5% (RoHS) 1
R14
8
116-304700jk2x-e Metal Film Resistor 470Ω 3W ±5% 10mm (RoHS) 2
R501,R50
2
110-14103j26-e
Resistor10K 1/4W ±5% CF 26mm
3
R503,R504,R510
,
110-14222j26-e Resistor 2.2K 1/4W ±5% CF 26mm TAP (RoHS) 1
R511,
110-14432j26-e Resistor4.3K 1/4W ±5% CF 26mm 1 R506,
110-14472j26-e Resistor 4.7K 1/4W ±5% CF 26mm
1
R505,
110-16102j26-e Resistor 1K 1/6W ±5% CF 26mm
1
R153,
110-16103j26-e Resistor10K 1/6W ±5% CF 26mm
10
R128,R130,R149,R150,R305,R306,R308,R311,R314,R319,
110-16104j26-e Resistor 100K 1/6W ±5% CF 26mm
3
R122,R126,R307
,
110-16153j26-e Resistor15K 1/6W ±5% CF 26mm 1
R107,
110-16182j26-e Resistor 1.8K 1/6W ±5% CF 26mm
1
R145,
110-16203j26-e Resistor 20K 1/6W ±5% CF 26mm
1
R309,
110-16221j26-e Resistor220Ω 1/6W ±5% CF 26mm
1
R144,
110-16222j26-e Resistor 2.2K 1/6W ±5% CF 26mm
1
R102,
110-16223j26-e Resistor 22K 1/6W ±5% CF 26mm
1
R316,
110-16333j26-e Resistor33K 1/6W ±5% CF 26mm
1
R310,
110-16393j26-e Resistor 39K 1/6W ±5% CF 26mm
1
R151,
110-16434j26-e Resistor 430K 1/6W ±5% CF 26mm
1
R312,
110-16473j26-e Resistor 47K 1/6W ±5% CF 26mm
2
R106,R129,
110-16474j26-e Resistor 470K 1/6W ±5% CF 26mm
1
R127,
110-16562j26-e Resistor 5.6K 1/6W ±5% CF 26mm
1
R152,
110-16621j26-e Resistor 620Ω 1/6W ±5% CF 26mm
1
R160,
110-16751j26-e Resistor 750Ω 1/6W ±5% CF 26mm
1
R315,
110-16755j26-e Resistor 7.5M 1/6W ±5% CF 26mm
1
R313,
116-161002f26-e metal film Resistor10K 1/6W ±1% MF 26mm
2
R301,R303,
116-161202f26-e metal film Resistor 12.0K 1/6W ±1% MF
1
R302,
116-162200f26-e metal film Resistor 220Ω 1/6W ±1% MF
1
R317,
116-162202f26-e metal film Resistor 22.0K 1/6W ±1% MF
1
R318,
Capacitors
138-5478m80-e large aluminum ec 4700uF 80V ±20% 85℃ (RoHS) 2
C501,C50
2
132-a103ja03-e Mylar Capacitor 0.01u 100V (RoHS) 2
C103,C10
4
132-103kd00-e mylar Capacitor 0.01U 400V +/-10% long foot (RoHS) 1
C500
130-3f104z503-e base capacity 0.1U 50V +80/-20%
6
C107,C117,C122,C144, C320,C322
130-sl101k503-e base Capacitor 100P 50V SL ±10%
3
C302,C303,C306
,
132-103j503-e mylar Capacitor0.01uF 50V ±5% 2
C305,C317,
132-104ja03-e mylar Capacitor 0.1UF 100V ±5%
3
C123,C503,C504
,
132-273ja03-e mylar Capacitor0.027UF 100V ±5% 1
C143,
135-3106m50-e electrolytic Capacitor 10uF 50V ±20%
2
C319,C321,
135-3107m10-e electrolytic cap 100U 10V ±20%
2
C114,C115,
135-3107m35-e electrolytic cap100U 35V ±20%
2
C507,C508,
135-3225m50-e electrolytic cap 2.2U 50V ±20%
1
C509,
135-3226m16-e electrolytic cap 22U 16V ±20%
1
C304,
