Part number Description Qty Reference Designator
MAIN PCB
135-3226m50-e electrolytic cap 22U 50V ±20%
2
C505,C506,
135-3227m16-e electrolytic cap 220U 16V ±20%
1
C118,
135-3476m16-e electrolytic cap47U 16V ±20%
1
C318,
Semiconductors
190-16tl074cn-e *I.C TL074CN ST (RoHS) DUAL OP-AMP 1
U301
192-161tip31c-e Transistor TIP31C SGS (RoHS) NPN
1
Q501
192-161tip32c-e TransistorTIP32C SGS (RoHS) PNP 1
Q502
197-00kbu606g-e diode6A 800V KBU606G (RoHS) BRIDGE
1
D501
197-141n4004-e diode1N4004 (RoHS)
2
D110,D504
192-027c1815gr-e Transistor 2SC1815GR TOSHIBA(RoHS) NPN 5
Q108,Q109,Q113,Q301, Q302,
192-027c2235y-e Transistor2SC2235Y TOSHIBA (RoHS) NPN 1
Q111,
192-028a1015gr-e Transistor 2SA1015GR TOSHIBA(RoHS) PNP
3
Q101,Q107,Q112,
192-1572n5551-e TransistorFSC 2N5551 (RoHS) NPN 2
Q114,Q115,
192-1582n5401-e TransistorFSC 2N5401 TO-92 (RoHS) PNP
1
Q503,
197-031n4148-e diode100mA 75V SIGNAL 1N4148
4
D102,D103,D104,D105,
199-15000625-e zener diode HZ6C2 RENESAS (6.2v) 1
D101,
199-15001605-e zener diode HZ16-2 RENESAS (16v)
1
D502,
Miscellaneous
120-1000003-e inductor10W AI YT-C3104-005 1CRHW354708LTB (RoHS) 2
FB1,FB2
109-1ttc802j0-e Thermister TTC-802(JS) NTC long foot(RoHS) 1
TH1
162-50129001-e CABLE ASS'Y wire 120mm AWG28 WHT (RoHS)
1
W201
171-urwh124d-e Relay RWH-SH-124D (1600 ohm) (RoHS)
1
RL1
175-1d02v01-e
Wire connector&base 2PIN PITCH=3.96mm (RoHS) 1
M100
175-1d03v01-e
Wire connector&base 3 PIN PITCH=3.96mm (RoHS) 1
M500
CLASS D ASS'Y PCB (Replacment of entire module is recommended, part# 051-B00012A-E).
Resistors
118-120610r0j-e SMDresistor 10.0Ω 1206 5% (RoHS) 2 R22,R23
118-12061001j-e SMDresistor 1.00K 1206 5% (RoHS) 4 R2,R11,R29,R30
118-12061002j-e SMDresistor 10.0K 1206 5% (RoHS) 3 R7,R9,R25
R31,R32,R33,R34,R35,R36,R37,R38
R39,R40,R41,R42,R43,R44,R45,R46
118-12062002j-e SMDresistor 20.0K 1206 5% (RoHS) 1 R26
118-12062201j-e SMDresistor 2.20K 1206 5% (RoHS) 3 R6,R13,R16
118-12062701j-e SMDresistor 2.70K 1206 5% (RoHS) 1 R10
118-12063000j-e SMDresistor 300.0Ω 1206 5% (RoHS) 1 R24
118-12063301j-e SMDresistor 3.30K 1206 5% (RoHS) 4 R14,R15,R27,R28,
118-12063902j-e SMDresistor 39.0K 1206 5% (RoHS) 1 R3
118-120647r0j-e SMDresistor 47.0Ω 1206 5% (RoHS) 2 R20,R21
118-12064700j-e SMDresistor 470Ω 1206 5% (RoHS) 1 R8,
118-12064701j-e SMDresistor 4.70K 1206 5% (RoHS) 3 R1,R5,R12,
118-12064702j-e SMDresistor 47.0K 1206 5% (RoHS) 1 R17
118-12064704j-e SMDresistor 4.70M 1206 5% (RoHS) 1 R4,
Capacitors
128-e106ma01k-e
crossver cap 10UF 100V 20% 105℃ long foot (RoHS)
2 C16,C17
141-c0220k50-e
SMD Capacitor 22pF 50V 10% 1206 SMT NPO (RoHS) 1
C5,
141-c0561k50-e SMD Capacitor 560pF 50V 10%
1
C6,
141-c5104m50-e
SMD Capacitor 1206 Y5V 0.1uF 50V ±20% (RoHS) 8
C2,C3,C7,C8,C9,C10,C11,C15,
141-c7223k50-e SMD Capacitor 0.022uF 50V 10%1206 X7R (RoHS) 1
C13,
141-c0101k50-e
SMD Capacitor 100pF 50V 10% 1206 NP0 (RoHS) 1
C4,
141-d7104ka0-e SMD Capacitor 0.1uF 100V 10% 1210 X7R (RoHS)
2
C12,C14
141-d7104kb5-e SMD Capacitor 0.1uF 250V 10% 1210 X7R (RoHS) 4
C1,C18,C19,C20,
118-12061201j-e SMDresistor 1.20K 1206 5% (RoHS) 16
