Part number Description Qty Reference Designator
CLASS D ASS'Y PCB (Replacment of entire module is recommended, part# 051-B00012A-E).
Semiconductors
190-16tl072dts-e
SMD I.C. TL072CDT SGS THOMSON DUAL OP-AMP 1
IC1,
192-09124126qs-e SMD Transistor 2SC2412K-T146Q/R
3
Q1,Q4,Q5,
192-09139066rs-e SMD Transistor 2SC3906K-T146R ROHM
2
Q2,Q8,
192-09210376qs-e SMD Transistor 2SA1037K-T146Q/R
2
Q7,Q9
192-09215146rs-e SMD Transistor2SA1514K-T146R ROHM
2
Q3,Q6,
197-03rls4148s-e SMD Transistor RLS4148-TE11 ROHM
6
D1,D2,D3,D4,D5,D6,
192-232irf9640-e FET IRF9640 IR P-CH TO220(RoHS) 1
Q10
192-233f640n-e Transistor IRF640N INTERNATIONA(RoHS) 1
Q11
199-15000563s-e
SMD ZENER 5.6V 5% PHILIPS BZX84-C5V6 (RoHS) 2
Z1,Z2,
199-1500120s-e
SMD ZENER 12V 5% PHILIPS BZX84-C12 (RoHS) 2
Z5,Z6,
199-15001503s-e
SMD ZENER 15V 5% PHILIPS BZX84-C15 (RoHS) 2
Z3,Z4
Miscellaneous
122-14121m4191-e
Ferrite core LS-A6206-ST EFD-30 (RoHS)
1
L1
122-14350j4180-e
chock coil35uH Ferrite Core 25 Milliohm (RoHS)
1
L2
175-9f40hr2-e wire connector & base 40PIN (RoHS) 0.2
MISCELLANEOUS/MECHANICAL
350-FM04012D106-E ψ4*12 wood screw(RoHS) 4
352-AM03010D066-E ￠3*10 Ptype tapping screw(RoHS) 3
352-AM03008D041-E ￠3*8 Btypetapping screw (RoHS) 4
150-r4055900-e
power Xformer I/P:120V/60Hz TT0900008720 (RoHS) 1 T501
152-u602015-e
line cord polar SVT FT-2 6FT double insulator (RoHS) 1
154-k31505t0-e fuse 3.15A 250V 30mm UL/CSA /PSE (RoHS) 1 F501
155-63032i-e fuse holderHTB-32I 30mm UL/CSA (RoHS) 1 for F501
180-pbr12c11s-e power switch PUSH BR12C11S (RoHS) 1 SW501
162-10082007-e WIRE RED 18AWG 80mm 8mm#1015 (RoHS) 1
362-FE-00013-0LAE PCB support L TYPE t=1.6mmS.P.C.C 89*9*1.6T (RoHS) 2
311-ABS-00028-0BAE LEVEL KNOB 46077-W P.V.C.(RoHS) 2
306-ABS-00004-0BAE rear Plastic housing 268*213*102 A.B.S UL (RoHS) 1
176-wjce1-e wire connector pinCE-1 (RoHS) 1
333-EVA-00096-0BAE EVA gasket wide side213*15*2.0mm(RoHS) 2
333-EVA-00097-0BAE EVAgasket wide side213*15*1.0t (RoHS) 2
333-EVA-00132-0BAE EVA gasket long side238*15*2.0mm (RoHS) 2
333-EVA-00133-0BAE EVAgasket long side238*15*1.0t (RoHS) 2
333-EVA-00220-0BAE EVAgasket long side225*15*1t UL(RoHS) 1
333-EVA-00188-0BAE EVA gasket 170x5x1t (RoHS) 1
130-3f104z503-e disc capacitor 0.1U 50V +80/-20% TAP(RoHS) 1 C110
193-201815t2-e insulator (RoHS)
352-HM03012D086-E ￠3*12 Btypetapping screw black (RoHS)
317-000-00037-0LAE panel M3 solder t=0.3 (RoHS) 1
323-AL-00056-0LAE heat sink 83.5*50.5*27.5H 1
333-EVA-00219-0BAE EVAgasket 150*15*1t UL(RoHS) 1
351-AM03008A078-E M3*8 machine screw (RoHS) 6
162-a040d005-e
spkr wire red and black#1015 add #205 250 pin(RoHS) 1
302-AL-00020-1LCE rear board 270*215*2.5T SUB10 AL (RoHS) 1
335-NYL-05015-0BAE wire clip SB4F-2 black(RoHS) 2
