jcb 19C-1E Quick Reference Guide

Please see operator manual for full details.
Daily Checks (10h) Check
Check condition of hydraulic cooling pack and system Visual Check
Check hydraulic oil level Visual Check
Check the condition of welded structure Visual Check
Check condition of bodywork and framework Visual Check
Check condition of attachments / optional equipment Visual Check
Grease attachments / optional equipment as required Lubricate
Check operation of all services i.e. excavator, dozer etc. Operate
Check operation of all electrical equipment i.e. horn, alarms etc. Operate
Check the track and running gear operation Operate
Check operation of the hour meter Visual Check
Check condition of the charging cable and the inlet connection Visual Check
Weekly Checks (50h) Check
Clean hydraulic cooling pack Clean
Check hydraulic hoses / pipework for leaks and damage Visual Check
Check condition of the rams Visual Check
Check the condition of the electrical wiring Visual Check
Check condition and tension of tracks Visual Check
Check presence of all pivot pin retaining bolts Visual Check
Grease slew ring bearing Lubricate
22
SERVICE / MAINTENANCE
19C-1E

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
