jcb 19C-1E Quick Reference Guide

Please see operator manual for full details.
26
Description
Weight
(kg)
I n t e n d ed U s e
H y d ra u l i c
R e q u i r e me n t s
Mechanical Quickhitch 13.7 Quick change of attachments None
Hydraulic Quickhitch 22 Quick change of attachments Quickhitch circuit
Bucket GP 150mm 20.2
General excavation / Bulk loading
loose material
None
Bucket GP 230mm 22.2
General excavation / Bulk loading
loose material
None
Bucket GP 300mm 24.4
General excavation / Bulk loading
loose material
None
Bucket GP 400mm 28.7
General excavation / Bulk loading
loose material
None
Bucket GP 460mm 30.3
General excavation / Bulk loading
loose material
None
Grading / Ditching Bucket
760mm
36.8
Grading, finishing, landscaping &
Ditching
None
Grading / Ditching Bucket
1000mm
44.9
Grading, finishing, landscaping &
Ditching
None
Earth Drill – 1500Nm 63.8 Drilling 160mm – 900mm holes 1x Hi-Flow aux service
Breaker – HM012T 107 Breaking up tarmac, concrete, rock 1x single acting aux service
Breaker –HM100Q 129 Breaking up tarmac, concrete, rock 1x single acting aux service
MACHINE ATTACHMENTS
19C-1E
ATTACHMENT WEIGHTS ARE A GUIDE ONLY, ALWAYS CHECK YOUR OWN ATTACHMENTS
Description I n t e n d ed U s e
110V Charging Cable Charging from a 110V supply (IEC60309 110V 16A)
230V Charging Cable Charging from a 230V supply (IEC60309 230V 16A)
Type E, F (Shuko) 230V Charging Cable Charging from a 230V supply (Type E, F (Shuko) 230V 16A)
ADDITIONAL ATTACHMENTS

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
