jcb 19C-1E Quick Reference Guide

Please see operator manual for full details.
Issue / FAQ Resolution / Answer
My machine will not start Ensure the service disconnect is turned on.
Verify the start up sequence has been followed (Page 16).
If machine still will not start contact dealer
I can’t activate the Hydraulics Here are some of the possible reasons:
• When the machine hydraulics are live and you lift the left
hand pod you will need to re-select ‘2-GO’ when the
pod is returned to the down position.
• The left hand pod is in the raised position.
• There is a fault on the keypad.
• Motor isn’t switched on.
• If there is an error on the machine and an error code is
displayed on the LCD screen – which would inhibit the
hydraulics.
If hydraulics still won’t activate contact dealer
Why is there an audible buzzer in
the cab when I’m lifting a large
load?
The lift overload warning system has detected a load that is
near the limits of the machine, reduce load to prevent
machine overturning.
Can I disable the lift overload
warning indicator when not
object handling?
To disable lift overload warning indicator when not object
handling, press button ‘C’ on the switch panel (refer to page
13).
500hrs Greasing - Does it matter
if greased every day?
No, there is no impact on life of the pivot pins or bushes
TROUBLESHOOTING / FAQ’S
19C-1E
27

jcb 19C-1E Specifications

General

Battery Type	Manganese laminated Lithium-ion
Battery Rated Capacity	14.8 kWh (3 Pack) 19.8 kWh (4 Pack)
Charging	On-board charger with direct connection from AC mains power supply
Charging Time	110V – 12 hrs 230V – 8 hrs
Fast Charging (Optional)	Off-board charger, with connection to 415V 3-Phase supply Charging time <2 hrs
System Voltage	48V
Motor Type	AC permanent magnet
Motor Power	7 kW continuous 20kW peak
Operating Modes	L – 1200rpm G – 1600rpm H – 1800rpm Auto Kick Up – 2300rpm, 2 speed tracking only
Thermal Limitations	Operation: -10oC to +46oC Charging: -10oC to +40oC
