jcb 8026 CTS Quick Start Guide

8 Please see operator manual for full details.
Cab & Switch Panel
A Graphic symbol
B Light bar
The rocker switches have two or three positions (as shown)
Fig 6
Fig 5
A Track control
B Swing/auxiliary pedals
C Horn
D Excavator controls
E Two-speed
tracking switch
F Dozer blade control
G Hand throttle control
H Instrument panel
J Ignition switch
K Auxiliary power socket
L Console switches
M Operator seat
N Swing/auxiliary switch
P Cab interior light
Operator Station Layout
Switch Panel
Work Lights
1 Off
2 On (Boom)
3 On (Boom & Cab)
Overload Warning System
1 Off
2 On (Boom)
Beacon
1 Off
2 On
Window Wipers
1 Off
2 On
2 Washer (if installed)
Fig 7
