8025 ZTS, 8026 CTS, 8030 ZTS, 8035 ZTS 9
Instrument Panel
A Fuel gauge
B Two speed (high engaged) indicator
C Auxiliary service (selected) indicator
D SAE controls (selected) indicator
E Air filter (blocked) indicator
F Glow plugs (on) indicator
G Hourmeter
H Indicator is not installed on this machine
J Indicator is not installed on this machine
K Engine oil (low) indicator
L Coolant temperature (high) indicator
M Charge (fault) indicator
Fig 8
Instrument Panel
