jcb JS220 - Operators Cab

3 - 1
Section C
Electrics
9803/6400
Section C
3 - 1
Issue 2*
Layout
Operator’s Cab
A296530
7 Left Excavator Joystick Control
8 Control Lock Lever
9 Left Console
10 Door Lock Release Lever
11 Optional Circuit Pedal (if fitted)
12 Operators seat
1 Right Console
2 Right Excavator Joystick Control
3 Display Monitor
4 Right Hand Track Control
5 Left Hand Track Control
6 Travel Speed Range Change Switch
88
55
44
66
!!
22
77
@@
11
33
99
00
