51 - 2
Dismantling
(continued)
2.
Remove the coil assembly (21) from the cap (22).
3.
Remove the spacer (20) from the coil assembly.
4.
Remove the inner housing (19). Remove slowly so that
the parts inside the housing do not fly out.
Section E
Hydraulics
9803/6400
Section E
51 - 2
Issue 2*
Solenoid Valve (8-spool)
*
316
