80 - 1
Section E
Hydraulics
9803/6400
Section E
80 - 1
Issue 1
Rotary Coupling
Schematic, Technical Data
Item Part Name
11 Axle
12 V-ring
13 Rotor
14 O-ring
15 Packing ring
16 Thrust plate
17 Hexagonal socket head
bolt
18 O-ring
19 Cover
20 Plug
21 Plug
