82 - 3
Dismantling JS200/JS240
(continued)
9.
Remove the V-ring 12 from the axle 11.
Note:
Do not reuse the V
-ring 12.
10.
Remove the 'O'-ring 14, and packing ring from the rotor
13.
Note:
Do not reuse the packing ring 15.
Section E
Hydraulics
9803/6400
Section E
82 - 3
Issue 1
Rotary Coupling
398
