jcb JS220 Service Manual

1 - 1
Section B
Body & Framework
9803/6400
Section B
1 - 1
Issue 2*
Torque Specifications
Torque Specifications JS200/JS240
*
Component Nm kgfm lb/ft Remarks
Counterweight 1059.1-1235.6/1333.7-1549.5 108-126/136-158 780-910.98/983.28-1142.3 Apply 262
Turntable Bearing
(Lower Frame) 521.0-608/784-914 53.1-62/79.9-93.2 383.91-448.26/577.67-673.83 Apply 262
Turntable Bearing
(Slew Frame) 521.0-608/784-914 53.1-62/79.9-93.2 383.91-448.26/577.67-673.83 Apply 262
Slew Equipment 521.0-608/784-914 53.1-62/79.9-93.2 383.91-448.26/577.67-673.83 Apply 262
Hydraulic Oil Tank 232.3 23.7-29.5 171.35-231.28 Apply 262
Fuel Tank 251.9- 25.7-29.5 185.81-213.28 Apply 262
Cab 127.4 13-14.5 93.99-104.83 Apply 262
