Programming
•Working with onesafety edge, it must be connected to IN1 of the transmitter. IN2
does not work. This band can work on R1 (mode 1) or R2 (mode 2) or sim-
ultaneously on the 2 relays (mode 3).
•Working with two safety edges (mode 4), the safety edge connected to IN1 act on
R1 and the safety edge IN2 connected on R2. In IN2 only mechanical band / contact
or 8k2 band is allowed..
Before programming, place the options selectors at the desired position. Any sub-
sequent change will require a receiver reset and reprogramming.
Press the PROG button and hold it until the desired mode is selected. LED's for R1 &
R2 will flash in sequence to select the correct operation mode.
There are four programming modes, depending on the inputs you wish to use of the
transmitter and the outputs required to activate on the receiver.
Mode
1 IN1 → R1: Safetyedge in IN1 on transmitter activates R1 on receiver
2 IN1 → R2: Safetyedge in IN1 on transmitter activates R2 on receiver
3
IN1 → R1 + R2: Safetyedge in IN1 on transmitter activates R1 and
R2 on receiver
4
IN1 → R1 and IN2 → R2: Safety edge in IN1 on transmitter activates
R1 on receiver and safety edge in IN2 on transmitter activates R2 on
reciever
The equipment remains in programming mode during 60s before programming the
first transmitter, and then 20s more for each of the following transmitters.
