11.Click the Sensor ON/OFF tab, then click the “Start” Screen Button to
restart the
Sensor ON/OFF Test.
12.To end the Test, click the “
Stop” Screen Button.
Table 12 lists the Sensor Tests, their functions and descriptions.
Table 12 Sensor Test Items
Test
No.
PC Screen
Sensor
Names
Sensor Purpose
PC Screen LED
Detected
NOT
Detected
Standby Operating
1
Transport
Entrance
Sensor
Detects a Banknote
present on the Entrance
Sensor
ON OFF
Flashing
WHITE
BLUE
2
Centering
Sensor
Detects a Banknote
present on the Center
Position Sensor
ON OFF
Flashing
WHITE
BLUE
3
Feed Out
Sensor
Detects a Banknote
existing on the Feed Out
Sensor
ON OFF
Flashing
WHITE
BLUE
4
Box Feed
Out Sensor
Detects a Banknote
existing on the Stack
Position Sensor
ON OFF
Flashing
WHITE
BLUE
5 Box Full Sensor
Detects that the Cash
Box is Full
ON OFF
Flashing
WHITE
BLUE
6
Box Near
Full Sensor
Detects that the Cash
Box is nearly full
ON OFF
Flashing
WHITE
BLUE
7
Pusher
Mechanism
Home Position
Sensor
Detects that the Pusher
Mechanism’s Pusher
Plate is correctly
positioned at the Home
Position
ON OFF
Flashing
WHITE
BLUE
8
Pusher Plate
Position Sensor
Detects that the Pusher
Mechanism’s Pusher
Plate correctly positions
itself at the half position
ON OFF
Flashing
WHITE
BLUE
9 Box Sensor
Detects that the Cash
Box is properly seated
ON OFF
Flashing
WHITE
BLUE
10
Centering Home
Position Sensor
Detects that the
Centering Mechanism is
correctly positioned at
the Home Position
ON OFF
Flashing
WHITE
BLUE
11
Box Lock
Sensor
Detects that the Cash
Box Release Lever is
locked
ON OFF
Flashing
WHITE
BLUE
12 GS_INS
Detects a Banknote
inserted into the Gated
Metal Bezel
ON OFF
Flashing
WHITE
BLUE
13 GS_Home
Detects when the Gate in
the GS Bezel is in the
Home Position
ON OFF
Flashing
WHITE
BLUE
14 GS_LOK
Detects when the Gate in
the GS Bezel is in the
Open Position
ON OFF
Flashing
WHITE
BLUE
15
BNF Entrance
Sensor
Detects a Banknote
existing on the BNF
Entrance Sensor
ON OFF
Flashing
WHITE
BLUE
NOTE: The Sensor status indicators should appear ON. If a Sensor’s status
indicator did not change from OFF to ON, it is not working properly.
