JDSU ORL-55 33
5 O
PERATION
Display absolute/relative level
Display relative level
The menu shows dB. Thus, the absolute level in dBm
is displayed when measuring.
Highlight dB and press [MENU ENTER] .
Display will show dB.
Display absolute level in dBm
The menu shows dBm. Thus, the relative level in dB
is displayed when measuring.
Highlight dBm and press [MENU ENTER] .
Display will show dBm.
dB (dBm) Toggle between relative (dB) and
absolute (dBm) mode.
The displayed mode can be
selected - thus it is the mode
actually not active.
Watt Change display unit to Watt.
In the dB/dBm line dBm will be
displayed when selecting Watt.
Store ABS -> REF Store displayed level as new
reference level. Display will switch
to relative mode automatically
(see „Setting the reference value”
on page 34).
Edit Ref. Level Edit reference level
(see „Setting the reference value”
on page 34).
Manage Memory Display and delete stored data
(see „Memory Management” on
page 39).
Configuration Change basic settings
(see „Selecting measurement
mode” on page 18).
