70 ORL-55 JDSU
9 S
PECIFICATIONS
General specifications
Display
Memory
Wavelength
detection
1)
1) Only together with JDSU OLS-55 Optical Light Sources. Only
works when power difference is < 20 dB.
Automatic switching and displaying up
to three wavelengths simultaneously
Reference
level
Transfer of measured value or entry of
any reference level
in the range -80 to +30 dBm,
one Reference Level for
each wavelength
Modulation
detection
2)
2) From -50 dBm (1260 to 1625 nm).
270Hz, 1kHz, 2kHz
Warm up time 15 min.
Optical adapter
system
Interchangeable adapter,
series BN 2150/00.xx
Fiber type 9/125
Connector type APC (Angled Physical Contact)
Display type Graphical display,
128 x 64 dots, b/w.
backlight function
(can be disabled)
Memory capacity 1000 measurement results,
350 data sets
Data readout/
Remote control
via USB interface
