Diagrammatic view
Reference Designation
1 Heat engine
2
POD rotary motor: Make the POD under the waterline turn 270 to
starboard
3 Clutch actuator: enables gear engagement and disengagement
4 Clutch: Mechanical linkage between the engine and the propeller shaft
5
TCU: (Transmission and Clutch Management) interface between the
clutch activator and the VMU
6
VMU (Vessel Management Unit): the brains of the system, it gathers all
the info from the system(joystick, control lever, TCU, POD..) and tells it
what to do
7
Throttle actuator: electric accelerator interface between the electric
control and the fuel pump
10
ENGINE
