Jeanneau 53 - Schematic Diagram

17/154
119635
Index G
SCHEMATIC DIAGRAM - VERSION EUROPE
REF Designation
1 Connection kit gas bottle
2 Drain
3 Gas cylinder
4 Connection kit gas copper
5 PVC girdled sleeve
6 Gas appliance connection kit
7 Wire passage
2
gaz
GAZ
1
3
2
6
7
4
5
SAFETY
