OPERATION
Waste water from the sink, washbasins and heads is drained off by thru-hull fittings with
ball valves (the valve is closed when the valve handle is perpendicular to the hose, the
valve is open when the valve handle is in line with the hose).
All the floors have holes (limber holes) for the water flow.
A watertight bilge tray under the engine receives the possible oil leaks.
A main sump located above the ballast receives water from the bilges.
.The main sump is partially drained by an electric or a manual pump. Regularly dry the
sump with a sponge.
Foot pump
Selection valve -
Sea water / House water
Under the sink
Control
Shore freshwater supply
Operation:
There is a non-return valve on the circuit directly supplying the water pump. There is
no water valve selection of the wharf / House water.
WARNING
Turn off shore water before leaving the vessel.
Connection
