Index G
GENERAL INFORMATION
ELECTRICAL PANEL
The electrical switchboard does not require any routine maintenance. In case an electric
appliance is not energized, check:
- The main power supply (batteries, battery switches).
- The switches and circuit breakers on the line.
- the relevant electrical unit.
REF Designation
1 Electrical panel "DC AMPS / 12 VOLTS DC"
2 Multi-function display
3 Change over switch - voltmeter inlet / Water gauge / Fuel oil
gauge
4 Contrast selector
5 Voltmeter selector
6 Water meter selector
7 Fuel meter selector
8 12V DC socket electrical panel
18 "Interior lighting" general circuit-breaker
19 "Navigation light/ engine light" switch
21 "Anchor light" switch
22 "Deck lighting" switch
23 "Auxiliary" switch (optional)
24 "Navigation electronics" switch
25 Switch - bilge pump
26 Switch - water unit
27 "Refrigerated unit" switch
A6 bipolar circuit breaker "water heater"
A7 bipolar circuit breaker "battery charger"
A8 Bipolar circuit breaker "AC sockets"
A10 Live shore power line warning light - "Shore Power"
A11 Warning light - reversal of polarity
A12 Voltmeter
9
ELECTRICAL EQUIPMENT
