- 33 -
Diagram of the layout - Bilge pumps
Reference Designation Rate
1 Manual bilge pump 32p/minute (*)
2 Manual bilge pump lever
3 Electric bilge pump 108p/minute
3’ Electric bilge pump 108p/minute
4 Electric bilge pump switch
(*) 45 strokes/minute
If 70 stroke/minute: rate 35p/minute
5
SAFETY
