Jeanneau NC14 - Layout Diagram

- 81 -
7.3.2 Layout diagram
AC electrical system - Version: Europe
7
PQ10-3x10mm²
32A
PQ1-3x6mm²
PQ11-3x10mm²
32A
PQCL1-3x6mm²
PQCL10-3x10mm²
G2-3x10mm²
32A 230V 50hz en eu rope
32A 230V 50hz en eu rope
50A 230V 50hz en e urope
PQCL2-3x10mm²
G4-3x10mm²
DIFF C 50 DIFF C 50
G1-3x10mm² G3-3x10mm²
C xx C xx C 16 C 16 C 16 C 16 C 16 C 16 C 16 C 16C 16
LPG
230AC 12DC 230AC 12DC 230AC 12DC
5
C xx C xx C xx C xx C xxC xx
AC SYSTEM
