Jeanneau NC14 - Page 82

- 82 -
AC electrical system - Version: US
PQ11-3x10mm²
G2-3x10mm²
110A 115V 60hz aux US
G4-3x10mm²
PQCL2-3x10mm²
PQ10-3x10mm²
PQCL10-3x10mm²
X
Y
G
W
phase 1
phase 2
neutre
terre
110V
110V
220V
50A
50A
C 50
PQ1-4x16mm²
50A 115V 60hz aux US
DIFF C 50 DIFF C 50
PQ1A-4x10mm²
DIFF C 50 DIFF C 50
G1-3x10mm² G3-3x10mm²
C xx C xx C 16 C 16 C 16 C 16 C 16 C 16 C 16 C 16C 16
LPG
230AC 12DC 230AC 12DC 230AC 12DC
5
C xx C xx C xx C xx C xxC xx
