- 52 -
Operation:
- Insert the locking key in the panel. This operation enables the battery breaker control
switches to be operated.
- Operate the push button.
The battery breaker is OFF when the indicator light is out.
The battery switch is ON (engaged) when the red indicator light is lit.
- To turn off the battery breakers, turn the key and press the push buttons.
Designation (from left to right)
Control of the battery breaker - Common negative
Control of the battery breaker - Service positive
Control of the battery breaker - Starboard engine
Control of the battery breaker - Port engine
- Turn off all battery breakers before leaving the vessel: risk of complete
discharging of whole battery bank.
- Avoid touching the battery breakers when they are live.
- Never switch off the battery breakers when the boat's engine is running (risk
of serious damage to the charging circuit).
