- 71 -
Menu: - AC source "Air conditioning"
This menu allows the AC current origin (shore supply or generator) to be
chosen for operating the air conditioning.
This function drives an electromagnetic inverter located in the engine room *.
7
DC INSTALLATION
1 - Supply line "House"
2 - Supply line "Air conditioning"
Shore supply blue-tinted: The socket is connected and
supplied. Access to the shore supply voltage display
Reversal of polarity (only for the 110V)
Padlocks: Indicates that the handle on the source selector
is engaged
Menu access: - Power supply - air conditioning
Menu access: - Supply to on-board circuit
Grey: Non current carrying
Blue: On-board circuit live
Orange: On-board circuit live but locked by setting the
handle on the source selector
Access the generator start menu by pressing the GE
button
Access the air-conditioning shore power supply menu
by pressing on the "2 socket" button
Access the shore power supply menu by pressing on
the "1 socket" button
