- 73 -
Menu: - On-board circuit source
This menu allows the AC current origin (shore supply or generator) to be
chosen for operating the air conditioning.
This function drives an electromagnetic inverter located in the engine room *.
* The source inversion packages installed in the engine room also have a removable handle to
alter the source origin manually.
7
On-board circuit
DC INSTALLATION
Voltage
Frequency
The orange circle indicates the
source selector position
Neutral
Generator
One press on the shore supply
button sets the on-board
selector switch to shore
supply. The orange circle
indicates that the switch is
made.
One press on the GE button
sets the on-board selector
switch to GE.The orange
circle indicates that the
switch is made.
